Brocade Communications Systems FastIron X Series Software Update page 70

show command output differences between 07.4.00 and 08.0.xx
show ip Brocade# sh ip ospf virtual-neigh 1
ospf Transit Area
virtual- 0.0.0.200
neighbor 2 Port
4/3/1*8193.213.111.213 FULL
address 192.213.111.111, priority 1, id 192.168.98.111
designated_router 0.0.0.0, backup_designated_router 0.0.0.0, interface
state Point To Point
state 8, event 5, mode 2, flags 1, option 2
ls_request_queue_count 0, ls_request_list_has_changed 0,
ls_req_can_be_sent 0
retransmit_queue_count 0, database_summary_queue_count 0
pkt_rx_count 0
inactivity_timer_enabled 1,
md5_sequence 0,
last_dd_sequence 43319,
last_dd_flags 24d713d9,
periodic_slave_hold_time_counter 6126
sptr_retransmit 0, sptr_retransmit_tail 0
sptr_database_summary 0
sptr_ls_request[1-5, 9] 0 0 0 0 0 0
interface 4/3/1*8/3/1, address 193.213.111.213, subnet/nexthop
193.213.111.111
sptr_nbr->retransmit_queue:
show sflow Brocade#sh sflow
sFlow version: 5
sFlow services are enabled.
sFlow agent IPv6 address: 10::12
4 collector destinations configured:
Collector IP 10.37.224.233, UDP 6343, Configured VRF: None, Using VRF:
default-vrf
Collector IP 10.37.224.233, UDP 6343, Configured VRF: sflow
Collector IP 10.37.224.164, UDP 6343, Configured VRF: None, Using VRF:
default-vrf
Collector IPv6 10::2, UDP 6343, Configured VRF: 6sflow
UDP source port: 8888 (Default)
Polling interval is 20 seconds.
Configured default sampling rate: 1 per 500 packets.
Actual default sampling rate: 1 per 500 packets.
The maximum sFlow sample size: 128.
sFlow exporting cpu-traffic is disabled.
123 UDP packets exported
0 sFlow flow samples collected.
sFlow ports: ethe 1/1/9 to 1/1/10 ethe 1/2/4 ethe 2/1/7 to 2/1/8 ethe
2/1/12
Module Sampling Rates
---------------------
Port Sampling Rates
-------------------
Port=1/1/9, configured rate=200, actual rate=200
Port=1/1/10, configured rate=500, actual rate=500
Port=1/2/4, configured rate=500, actual rate=500
Port=2/1/7, configured rate=500, actual rate=500
Port=2/1/8, configured rate=500, actual rate=500
Port=2/1/12, configured rate=400, actual rate=400
FastIron Ethernet Switch Software Upgrade Guide
53-1003632-02
Router ID Neighbor address options
192.168.98.111 192.213.111.111
Address state
periodic_inactivity_time_counter 10
sequence 43320, neighbor_sequence 0
last_exchange 0
last_dd_options 24d713d8
2
events count
5 0
The output is more
detailed.
The output is more
detailed.
