Figure 2 Product components
1 Turbidimeter
®
2 StablCal calibration set
3 Sample vials

Installation

Multiple hazards. Only qualified personnel must conduct the tasks described in this section of the
document.
This instrument is rated for an altitude of 3100 m (10,710 ft) maximum. Use of this instrument at an
altitude higher than 3100 m can slightly increase the potential for the insulation to breakdown, which
can result in an electric shock hazard. The manufacturer recommends that users with concerns
contact technical support.

Installation guidelines

Install the instrument:
• On a level surface
• In a clean, dry, well ventilated, temperature controlled location
• In a location with minimum vibrations that has no direct exposure to sunlight
• In a location where there is sufficient clearance around it to make connections and to do
maintenance tasks
• In a location where the power button and power cord are visible and easily accessible

Electrical installation

Connect to external devices (optional)

The instrument has three USB ports and one ethernet port. Refer to
optional external device documentation for more information.
• USB port—Connect to a printer, scanner, USB flash drive or a flow-through module.
• Ethernet port—Connect to an external PC or a communications network.
C A U T I O N
-BETA DRAFT-
4 Power supply with adapters
5 Dust cover
6 Vial stand
Figure 1 on page 8. Refer to the
English 9
