FLASHFORGE 3D PRINTER INVENTOR Quick Start Manual page 3

12
Extruder
13
14
3
4
5
6
7
1.Extruder Cable Bunch
5.Build Plate
9.Z-Axis Guide Rod
13.Turbofan
17.Side Panel
21.Power Switch
Getting to Know Your Inventor
11
15
1
2
8
9
18 19 20
2.Filament Guide Tube
6.Build Platform
10.Touch Screen
14.Turbofan Baffle
18.SD Card Input
22.Power Input
Camera
16
10
21 22
3.Y-Axis Guide Rod
7.Bracket
11.Cooling Fan
15.Left Nozzle
19.USB Input
23.Camera
02
23
17
4.X-Axis Guide Rod
8.Leveling
Knob
12.Spring Presser
16.Right Nozzle
20.Reset Button
