4.5.1 USB (P1)
The USB connector is a standard Type B USB receptacle.
Part Description
Type B USB receptacle
USB cable (provided with kit)
4.5.2 Audio (P3, P4)
These connectors are 3.5mm Stereo audio jacks.
Part Description
3.5mm stereo jack
3.5mm stereo plug to 3.5mm
stereo cable
4.5.3 Telephone (P5)
This is a standard 6 position 4 contact phone jack.
Part Description
Phone jack
ADSP-2191 EZ-KIT Lite Evaluation System Manual
Manufacturer
Mill-Max
Digi-Key
Mating Connector
Assmann
Digi-Key
Manufacturer
Shogyo
Mating Connector
Mouser
Manufacturer
Amp
Part Number
897-30-004-90-000
ED90003-ND
AK672-5
AK672-5ND
Part Number
SJ-0359AM-5
172-3504
Part Number
555165-2
4-38
