2. Connect the plug-in power supply to the Sunny WebBox and plug it into the socket-outlet
(see ➁ ).
☑ As soon as the "SYSTEM" and "POWER" LEDs glow green, the Sunny WebBox has started up
and is ready for operation. The start-up procedure can take up to 90 seconds.
– IF the "SYSTEM" or "POWER" LEDs do not glow green, refer to Section 14.

6.4 Configuring the Network Settings on the Computer

6.4.1 Information on Network Settings on the Computer

If you do not use the Sunny WebBox Assistant for initial commissioning of the Sunny WebBox, you
need to make the network settings manually on the computer. To do so, first configure your computer
based on the Sunny WebBox network range on delivery. The settings are described for the following
operating systems:
• Windows Vista/Windows 7
• Windows XP/Windows 2000
If you use a different operating system, refer to the manual of your operating system to find out how
to set the computer IP address to 192.168.0.100 and the subnet mask to 255.255.255.0.
User rights in the operating system
You will need the appropriate user rights to change the computer's network settings.
Without the necessary user rights, you will not be able to start up the Sunny WebBox. If
you have any questions, contact your network administrator.

6.4.2 Windows 7, Windows Vista

1. Start the computer.
2. In Windows select "Start"
3. Enter "ncpa.cpl" in the search field and press Enter.
☑ The "Network connections" window opens.
4. Double-click the LAN connection used to connect the Sunny WebBox.
– If Windows displays several LAN connections, there are probably several network
connections installed on the computer. Ensure that you select the correct network connection,
with which the computer is connected to the Sunny WebBox. If necessary, refer to the
computer manual.
– In the event that no LAN connection is displayed, refer to Section 14.
☑ The "Local Area Connection Status" window opens.
