UDI R/C Discovery2 Operation Manual page 7

Exploded View
1
2
3
4
5
6
7
6
8
9
10
11
4
5
6
12
6
9
No. Name
1
Drone Cover Housing
2
A propeller (Clockwise)
3
Motor upper holder A
4.
Gears
5
Aluminum Spindle
6
Bearing
7
Rear LED board(Red)
Counterclockwise motor
8
(Black and white wire,
white plug)
17
18
19
13
20
14
14
21
22
15
23
15
14
14
13
13
24
16
No. Name
9
Lamp hood
10
B propeller(Counterclockwise)
11
Motor upper holder B
12
Front LED board(Green)
13
Motor holder
14
Square carbon fiber tube
15
Landing Gear
Clockwise motor
16
( Red blue wire,red plug)
7
www.udirc.com
13
16
No. Name
17
Receiver board
18
Power switch
19
Receiver board bracket
20
Power board
21
Video adapter board
22
Battery box
23
Battery adapter board
24
Camera
10
11
4
5
6
7
6
9
2
3
4
5
6
6
12
8
9
