8. Close the spa cover and fasten the cover tie downs. Cover the spa
cover with two pieces of plywood to evenly distribute the weight of
snow and ice. Secure a plastic sheet, or tarp, over the spa cover and
plywood.
9. Replace the equipment access door, if removed.
OPENING INSTRUCTIONS:
1. Remove plywood and plastic sheet. Open the spa cover by
unfastening the cover tie downs.
2. Follow the Start-up and Refill Procedures in the Operating
Instructions section of the Owner's Manual. Do not install filters to
prevent them from exposure to the anti-freeze.
3. As part of this process, superchlorinate the spa water by adding
three teaspoons of chlorine (sodium dichlor) per 950 liters of spa
water into the filter compartment. This is twice the normal amount of
chlorine needed for superclorination. This extra amount of chlorine is
needed to destroy the anti-freeze.
NOTE: A defoamer may be needed to decrease the amount of foam
caused by the anti-freeze
4. Drain your spa to ensure removal of anti-freeze. Do not drain water
on grass or plants due to excessive chlorine level.
5. After the spa has completely drained, re-install your filter and follow
the Start-up and Refill Procedures in the Operating Instructions
section of the Owner's Manual.
IMPORTANT: Always keep spa covered when not in use, whether it is
empty or full.

FILTER SYSTEM

The filter lid on the spa is NOT designed to support heavy weight loads
and should not be used as a seat. In extreme cases, the lid could crack
and break. This occurrence is considered abuse and is not covered
under the warranty.
LIMELIGHT Collection spas are equipped with one filter cartridge, sized
to meet the needs of the jet pump system.
As with any water filtering system, the filter cartridge may become
clogged, resulting in reduced water flow. It is important to maintain a
clean, unobstructed filtering system. This not only provides the maximum
performance from the jets, but allows the 24 hour filtration system to
function effectively. Watkins Manufacturing Corporation recommends
the filter cartridge be cleaned (by soaking in a filter cleaner to dissolve
minerals) at least once every month.
IMPORTANT: The frequency and duration of use, and the number of
occupants all contribute to determining the appropriate time between
filter cleanings. More use means that more frequent filter cleanings are
required. Failure to maintain the cartridges in a clean, unobstructed
manner will result in reduced water flow through the heater assembly
that may cause the High-Limit Thermostat, Heater Thermal Cut-off or
Circulation Pump Thermal Cut-off to trip. If this high-limit or thermal cut-
off trip occurs during sub-freezing temperatures and goes unnoticed, the
spa water may freeze. Any damage to the spa (due to freezing) caused
as a result of poor maintenance (stated under misuse or abuse in the HOT
SPRING spa Limited Warranty), will not be covered by your spa warranty.
WARNING: To reduce the risk of injury to persons using the spa,
DO NOT remove the suction fittings (filter standpipes) located in the filter
compartment and do not sit on the filter lid, in extreme cases the lid
could crack and break. This occurrence is considered abuse and is not
covered under warranty.
Spa Care and Maintenance
SECONDARY SUCTION SCREEN
Located in the foot well of your spa are three secondary suction screens.
The screen is used as a filter to prevent dirt from circulating through the
system.
WARNING: Do not use the spa with the suction screens removed.
FILTER CARTRIDGES
REMOVAL & CLEANING
1. Disconnect the spa from the power supply by tripping both of the GFCI
breakers located in the subpanel. Unplug power cord for 115V models.
2. Remove and carefully set aside the filter compartment cover.
3. Remove any floating items from within the filter compartment.
4. Turn the filter retainer handle (located on the top of the filter cartridge)
counterclockwise until the retainer can be removed from the filter
standpipe.
5. Remove the filter retainer and cartridge.
IMPORTANT: Never remove the filter standpipes when debris is
present in the filter compartment. Debris may find its way into the
internal plumbing which may result in blockage. NEVER REMOVE
SUCTION FITTINGS.
6. Always clean standard filter using a filter degreaser, such as
FRESHWATER Filter Cleaner, to remove mineral and oil buildup.
Simply soak the filter in the degreaser according to the package
directions, then place the filter on a clean surface and spray until clean
using a garden hose. It may be necessary to rotate the filter while
spraying to remove any debris lodged between the filter pleats.
7. To reinstall the filter cartridge, reverse the order of steps in which it
was removed. Do not overtighten!
WARNING: Do not use the spa with the filter cartridges, or filter
standpipe(s) removed!

CARE OF THE SPA PILLOWS

The spa pillows will provide years of comfort if treated with care. They
have been positioned above the water level to minimize the bleaching
effects of chlorinated water, and other spa water chemicals. To extend
their life, whenever the spa shell is being cleaned, the spa pillows
should be removed and cleaned. Body oils can be removed with a mild
soap and water solution. ALWAYS rinse off the spa pillows thoroughly
to remove any soap residue. The pillows can be conditioned with HOT
SPRING Cover Shield after cleaning. If the spa is not going to be
used for a long period of time (that is during a vacation, or if the spa is
winterized), or when the spa water is being super-chlorinated, the spa
pillows should be removed until the next spa use.
To remove and replace the spa pillows:
1. Carefully pull and lift on one end of pillow to stretch pillow (longer)
until the pillow is released from the plastic retainer. Once one end
is released, push pillow in opposite direction to remove from other
retainer.
2. Align pillow.
3. Slide one end of pillow onto the spa retainer.
4. Pull other end of pillow; using both hands lift pillow above retainer and
with a stretching motion slide pillow recess onto retainer.
Page 25
