Maple Systems HMI5000 Series Information Sheet page 5

EZware Settings
The following table lists the communications settings that must be configured in
EZware. These settings can be found in the Edit-System Parameters menu under the
Device tab. Please note:

The Recommended Settings column provides the recommended setting
based upon the default settings most commonly used in the GE
Intelligent Platforms 90-30 Series controllers.
 The Options column lists EZware's options; your PLC may not support
every option
Name
Name:
HMI or PLC:
Location:
PLC type:
PLC I/F:
PLC default station
no.:
Use UDP
Settings: IP Address:
Settings: Port No:
Settings: Timeout
(sec)
Settings: Turn around
delay (ms)
