Maple Systems HMI5000 Series Information Sheet

Omron fins/tcp (ethernet)
Hide thumbs Also See for HMI5000 Series:
1
2
3
4

Advertisement

Quick Links

Download this manual
C O N T R O L L E R
Maple Model(s)
HMI5000 Series
Summary
Maple Systems' HMI5000 Series Human/Machine Interface Terminals (Maple HMIs)
communicate with devices that support the Omron FINS protocol. When configured with
EZware, the Maple HMI is the master in a point-to-point single master, multiple slave format.
Please refer to the Installation and Operations Manual for information on connecting multiple
Maple HMIs to a single PLC port.
Compatible PLCs
Family
FINS/TCP Devices
Communications Cable
The Maple HMI should be connected to the Ethernet port on the PLC. If the HMI is connected
directly to the PLC, use a crossover cable from the HMI to the PLC.
A list of communications cables offered by Maple Systems as well as cable assembly
instructions to assist you in assembling your own communications cable are available on our
website at www.maplesystems.com.
WARNING If your communications cable is not wired exactly as shown in our cable
assembly instructions, damage to the HMI or loss of communications can
result.
Maple Systems Inc., 808 134th Street SW, Suite 120, Everett, WA 98204-7333 – www.maplesystems.com
.
1036-0204
I N F O R M A T I O N
PLC or Controller
Omron FINS/TCP
(Ethernet)
Model
All
Page 1 of 4
S H E E T
Rev. 01, 12/03/2013

Advertisement

loading
Need help?

Need help?

Do you have a question about the HMI5000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Maple Systems HMI5000 Series

Summary of Contents for Maple Systems HMI5000 Series

  • Page 1 PLC, use a crossover cable from the HMI to the PLC. A list of communications cables offered by Maple Systems as well as cable assembly instructions to assist you in assembling your own communications cable are available on our website at www.maplesystems.com.
  • Page 2 Accessible PLC Memory Register Memory The following table lists the PLC’s register memory ranges that the Maple HMIs are able to access. Please note that your PLC’s memory range may be smaller or larger than that supported by these HMIs. The following register memory can be displayed in 16 or 32-bit format on the Maple HMI.
  • Page 3 Location Local Local, Remote if PLC connected thru another HMI Omron (Ethernet – PLC type: FINS/TCP) PLC I/F: Ethernet Ethernet Maple Systems Inc., 808 134th Street SW, Suite 120, Everett, WA 98204-7333 1036-0204 Page 3 of 4 Rev. 01, 12/03/2013...
  • Page 4 Recommended Name Options Important Notes Settings 0.0.0.0- Must match the controller Settings: IP Address: xxx.xxx.xxx.xxx 255.255.255.255 port’s IP Address Settings: Port 9600 0-65535 Must be 9600. Adjust if longer timeout is Settings: Timeout 0.1 to 25.5 required (sec) Timeout period between OIT Settings: Turn around 0-1000 polls...
