- Page 1 USER MANUAL MAPLE MODULAR PLC CPU Modules MODELS PLC-ES1616P • PLC-ES0808P • PLC-ES0806R • 1010-1154 REV 1.0...
-
Page 2: Table Of Contents
Contents General Specifications ........7 Performance Specifications .........8 Device & Address..........11 Internal I/O Specifications .........12 Features of CPU..........13 CPU I/O Pin Maps..........14 Communication Interface........16 Built-in Comm. Specification ......17 P r o d u c t D i m e n s i o n s........19 Product Warranty ..........21... - Page 3 Reproduction of contents, in whole or part of this manual, without written permission from Maple Systems Inc. is prohibited. Safety symbols are classified into two categories, “WARNING” and “CAUTION”. Warning: This symbol describes situations that could cause major or fatal injury to the user.
- Page 4 Design Precautions ( Warning) Please install a safety circuit to protect the entire control system in case of an unexpected power shut-down or PLC module malfunction. Such anomalies may severely compromise the integrity of the overall system. External to the PLC, please install circuits and switches to safeguard the system from mechanical damages (ex.
- Page 5 Precautions for mounting ( Caution) Use the PLC in an environment that meets the general specifications given in this manual. Using this PLC in any environment outside the range of the general specifications could result in electric shock, fire, malfunction, or damage to or deterioration of the product. Please ensure that each module is installed correctly in its place.
- Page 6 Precautions for test run and repair ( Warning) Please do not touch the terminals when the power is on. Doing so could cause an electric shock or malfunctions. When cleaning or tightening the screw, turn off the power of PLC and all other systems. Failure to do so could cause an electric shock or malfunctions.
-
Page 7: General Specifications
General Specifications Items Specification Standards Ambient -10℃–60℃ Temp. Storage -25℃–80℃ Temp. Ambient 5–95% RH, Non-condensing Humidity Storage 5–95% RH, Non-condensing Humidity For discontinuous vibration Frequency Acceleration Amplitude Times 5 ≤ f < 9 Hz 3.5 mm 10 times in X, Y, Z 9 ≤... -
Page 8: Performance Specifications
CPU Performance Specifications Specification PLC-ES1616P Items PLC-ES0808P PLC-ES0806R DC 12/24 VDC Power Note: 24 VDC is needed for Relay Outputs 120 g Weight Cyclic Execution, Time Driven Interrupt Program Control Method Indirect method, Directed by program instruction I/O Control Method... - Page 9 CPU Performance Specifications Scan, Subroutine, Initialize (COLD), Initialize (HOT), Periodic interrupt Initializing special card, PID control, I/O Input module filter setting, High- Special speed Counter Configuration Supporting Program User protocol (Serial), User protocol (Ethernet), MODBUS TCP/RTU Master, Communication High-Speed PLC link, Security SFC Program FBD (Function Block Diagram), FBD Extension –...
- Page 10 CPU Performance Specifications RS-232C (Max 115200 bps), RS-485/422 (Max 57600 bps): MAPLELOGIC Serial Loader, Modbus RTU Master/Slave, User Protocol 10/100Base-T/TX Ethernet MAPLELOGIC Loader, Modbus TCP Slave Max 16 logs (Power, Mode, Error) Event log 1 Phase: 20 kHz Max. Counting Speed 2 Phase: 10 kHz I/O Reservation, RTC, Online Edit Features...
-
Page 11: Device & Address
Device & Address ► Device - Input: X - Output: Y - Sub Relay: M - Keep Relay: K - Timer: T - Counter: C - Data Device: D - Sub Data Device: @D - Link Relay: L - Step Control Relay: S - Special Relay: F - Index Register: R ►... -
Page 12: Internal I/O Specifications
Internal I/O Specifications Items DC Input Relay Output TR Output DC 24 V Rated I/O DC 12 V/24 V AC 220 V/DC 24 V DC 24 V Voltage (High Speed Counter) Rated I/O 4 mA 1 point 2 A/COM 5 A 1 point 0.2 A/COM 2 A Current CH1–4: DC 10 V/4 mA... -
Page 13: Features Of Cpu
Built-in Flash memory enabling permanent backup of the program without any separate battery. Recommendations on using USB Cable ► 1. Recommended to use MAPLE SYSTEMS’s shielded cable within 3 m length. 2. In case of using a PC that is vulnerable to noises, it is recommended to use USB Hub or Isolator. -
Page 14: Cpu I/O Pin Maps
CPU I/O Pin Map ► PLC-ES1616P Inputs ► PLC-ES1616P Outputs... - Page 15 CPU I/O Pin Map ► PLC-ES0806R Inputs/Outputs ► PLC-ES0808P Inputs/Outputs...
- Page 16 PLC-ES1616P I/O Pin Map ► Terminal Block (ACC-TB32M) ACC-TB32 PLC-ES1616P * Terminal (ACC-TB32M) has its own terminal cable. Terminal Cable: ACC-SCB15M...
-
Page 17: Communication Interface
Communication Interface... -
Page 18: Built-In Comm. Specification
Built-in Comm. Specification Ch 1 Ch 2 Items RS-232C RS-485/422 MAPLE Protocol Comm. Mode Protocol Program MODBUS/RTU Master/Slave Master/Slave Data Bit 8 Bit Types Stop Bit 1 or 2 Bit Parity Even/Odd/None Synchronization Asynchronous Transmission Speed 1200–115200 1200–57600 Items Ethernet MAPLE Protocol Protocol Program Comm. - Page 19 Dimensions (Unit: mm) ▶ PLC-ES1616P (Unit: mm) ▶ PLC-ES0806R...
- Page 20 Dimensions (Unit: mm) ▶ PLC-ES0808P...
-
Page 21: Product Warranty
Product Warranty Warranty Statements are included with each unit at the time of purchase and are available at www.maplesystems.com. - Page 22 MEMO...
- Page 23 MEMO...
- Page 24 MAPLE SYSTEMS INC. 808 134th St SW #120 Everett, WA 98204 Phone +1 425-745-3229 Web: www.maplesystems.com 1010-1154 REV 1.0...
