Summary of Contents for Maple Systems PLC-FB0808P
- Page 1 USER MANUAL MAPLE MICRO PLC MODELS PLC-FB0808P • PLC-FB1616P0202 • PLC-FB1616R0202 • 1010-1153 Rev. 3.0...
-
Page 2: Table Of Contents
Contents General Specifications ........7 Performance Specifications .........8 Analog I/O Specifications ........9 Device & Address ..........10 I/O Specifications ..........11 Names of Parts and Mode Changes ....12 CPU Module Features........14 CPU I/O Pin Map..........15 Built-in Comm. Specifications ......18 Communication Interfaces .......19 Analog I/O Interfaces ........21 Dimensions............22 Product Warranty..........24... - Page 3 Reproduction of contents, in whole or part of this manual, without written permission from MAPLE SYSTEMS Inc. is prohibited. Safety symbols are classified into two categories, “WARNING” and “CAUTION”. Warning: This symbol describes situations that could cause major or fatal injury to the user.
- Page 4 Design Precautions ( Warning) Please install a safety circuit to protect the entire control system in case of an unexpected power shutdown or PLC module malfunction. Such anomalies may severely compromise the integrity of the overall system. External to the PLC, please install circuits and switches to safeguard the system from mechanical damages (ex.
- Page 5 Precautions for mounting ( Caution) Use the PLC in an environment that meets the general specifications given in this manual. Using this PLC in any environment outside the range of the general specifications could result in electric shock, fire, malfunction, or damage to or deterioration of the product. Please ensure that each module is installed correctly in its place.
- Page 6 Precautions for wiring ( Caution) Make sure to check the device’s regular voltage and sequence of terminals. Failure to do so may cause fire, electric shock and malfunctions. Make sure to tighten the screws with standard torque. Loose connections may cause a short circuit, fire or malfunctions.
-
Page 7: General Specifications
General Specifications Items Specification Standards Ambient -10 ℃–55 ℃ Temp. Storage -25 ℃–80 ℃ Temp. Ambient 5–95% RH, Non-condensing Humidity Storage 5–95% RH, Non-condensing Humidity For Discontinuous Vibration Frequency Acceleration Amplitude Times 5 ≤ f < 9 Hz 3.5 mm X,Y,Z Each direction, 10 times 9 ≤... -
Page 8: Performance Specifications
Performance Specifications Specification Items Remark PLC-FB0808P PLC-FB1616P0202 PLC-FB1616R0202 Power DC 24 VDC DC 12/24 VDC DC 12/24 VDC Current Consumption 120 mA 330 mA 400 mA Program Control Method Cyclic execution of stored program, Time Driven Interrupt I/O Control Method... -
Page 9: Analog I/O Specifications
Performance Specifications High Speed Counter Maximum: 1Ph 20 kHz, 2Ph. 10 kHz X axis: Position/Speed Control 100Kpps Positioning Y axis: Position control 5Kpps, Speed Control 100Kpps 32 Channels, Auto-Tuning USB Loader, RS-232C (1 CH, universal), RS-485/422 Communication Channels (1 CH, universal), Ethernet (10/100 Mbps auto-detect) Features RTC, Floating-point operation, Online edit Analog I/O Specifications... -
Page 10: Device & Address
Device & Address ▶ Device - Input: X - Output: Y - Sub Relay: M - Keep Relay: K - Timer: T - Counter: C - Data Device: D - Sub Data Device: @D - Link Relay: L - Step control Relay: S - Special Relay: F - Index register: R ▶... -
Page 11: I/O Specifications
I/O Specifications Item DC Input Relay Output TR Output Common (All Module PLC-FB1616R0202 PLC-FB0808P PLC-FB1616P0202 CPU’s) DC 12/24 V AC 220 V Rated I/O *12 VDC DC 12V or 24 VDC Voltage DC 24 V only used for HSC 220 Vac/24 Vdc,... -
Page 12: Names Of Parts And Mode Changes
Names of Parts and Mode Change ▶ Names of Parts PLC-FB0808P PLC-FB1616P0202 PLC-FB1616R0202... - Page 13 Names of Parts and Mode Change ▶ Mode change - Operation mode is changed using the mode switch. - The mode can be changed through MAPLELOGIC, but when the power is reset, RUN/STOP mode is decided based on the switch position.
-
Page 14: Cpu Module Features
Built-in flash memory enabling permanent backup of program without any separate battery. Recommendations on using USB Cable ► 1. Recommended to use MAPLE SYSTEMS’s shielded cable within 3m length. 2. In case of using PC that is vulnerable to noise, it is recommended to use USB Hub or Isolator... -
Page 15: Cpu I/O Pin Map
CPU I/O Pin Map PLC-FB0808P... - Page 16 CPU I/O Pin Map PLC-FB1616P0202...
- Page 17 CPU I/O Pin Map PLC-FB1616R0202...
-
Page 18: Built-In Comm. Specifications
Built-in Communication Specifications Items RS232C RS485/422 Ethernet MAPLELOGIC Comm. Protocol Protocol User Protocol MODBUS/RTU Master/Slave Master/Slave Slave Data Bit 8 Bit Types Stop Bit 1 or 2 Bit Parity Even / Odd / None Synchronization Asynchronous Transmission Speed 10/100 Mbps 1200–38400... - Page 19 Communication Interface (16 Point PLC) ▶ Serial Port PIN Map COMM NAME RS-232C RS-485...
-
Page 20: Communication Interfaces
Communication Interfaces (32 Point PLC) ▶ Serial Port PIN Map NAME COMM RS232C RS485 ▶ RS-485 Line Resistance Option If RS-485 communication is not stable because of the surrounding noises, use the “RS- 485 Resistance Option” switch to enhance the resistance. Turning on this option switch may improve the communication quality, but the available communication distance will decrease. -
Page 21: Analog I/O Interfaces
Analog I/O Interfaces (32 Point PLC) ▶ Analog I/O Interface PIN NAME Description Analog Input Ch.1 Terminal Analog Input Ch.2 Terminal DAV1 Analog Voltage Output Ch.1 Terminal DAV2 Analog Voltage Output Ch.2 Terminal DAI1 Analog Current Output Ch.1 Terminal DAI2 Analog Current Output Ch.2 Terminal ACOM Analog I/O COM... -
Page 22: Dimensions
Dimensions (Unit: mm) Model: PLC-FB0808P... - Page 23 Dimensions (Unit: mm) Model: PLC-FB1616P0202, PLC-FB1616R0202...
-
Page 24: Product Warranty
Product Warranty Warranty Statements are included with each unit at the time of purchase and are available at www.maplesystems.com. - Page 25 MEMO...
- Page 26 MEMO...
- Page 27 MEMO...
- Page 28 MAPLE SYSTEMS INC. 808 134th St SW #120 Everett, WA 98204 Phone +1 425-745-3229 Web: www.maplesystems.com 1010-1153 Rev. 3.0...
