C O N T R O L L E R
Maple Model(s)
HMI5000 Series
HMI5000P Series
Summary
Maple Systems' HMI5000 Series Human/Machine Interface Terminals (Maple HMIs)
communicate with GE Intelligent Platforms Series 90-30 and the VersaMax PLC using the
SRTP protocol. When configured with EZware-5000, the Maple HMI is the master in a point-
to-point single master, multiple slave format. Please refer to the Installation and Operation
Manual (Maple p/n 1010-1007) for information on connecting multiple Maple HMIs to a single
PLC port.
Compatible PLCs
PLC Family
Series 90-30
Communications Cable
The Maple HMI can be connected directly to the PLC's Ethernet port. If connecting directly
from the HMI to the PLC, use a crossover
Maple Systems as well as cable assembly instructions to assist you in assembling your own
communications cable are available on our website at www.maplesystems.com.
WARNING If your communications cable is not wired exactly as shown in our cable
assembly instructions, damage to the HMI or loss of communications can result.
Maple Systems Inc., 808 134th Street SW, Suite 120, Everett, WA 98204-7333 • www.maplesystems.com
.
1036-0145
I N F O R M A T I O N
PLC or Controller
GE Intelligent Platforms
90-30
(Ethernet)
PLC Model
374 plus
cable.
A list of communications cables offered by
Page 1 of 6
S H E E T
Rev. 02, 08/28/2013
Advertisement
Related Manuals for Maple Systems HMI5000 Series
Summary of Contents for Maple Systems HMI5000 Series
- Page 1 A list of communications cables offered by Maple Systems as well as cable assembly instructions to assist you in assembling your own communications cable are available on our website at www.maplesystems.com. WARNING If your communications cable is not wired exactly as shown in our cable assembly instructions, damage to the HMI or loss of communications can result.
-
Page 2: Plc Settings
PLC Settings The PLC’s IP address must be the same as that specified in EasyBuilder’s “IP Address” setting. Accessible PLC Memory Register Memory The following table lists the PLC’s register memory ranges that the Maple HMIs are able to access. Please note that your PLC’s memory range may be smaller or larger than that supported by these HMIs. - Page 3 Data Memory Registers 1-32768 ddddd Analog Input Registers 1-32768 ddddd Analog Output Registers 1-5000000 ddddddd Word Registers Maple Systems Inc., 808 134th Street SW, Suite 120, Everett, WA 98204-7333 • www.maplesystems.com 1036-0145 Page 3 of 6 Rev. 02, 08/28/2013...
- Page 4 Discrete Memory The following table lists the PLC’s discrete memory ranges that the Maple HMIs are able to access. Please note that your PLC’s memory range may be smaller or larger than that supported by these HMIs. The following discrete memory is displayable in single-bit format on the Maple HMI.
- Page 5 Settings: Timeout 0.1 to 25.5 required (sec) Timeout period between HMI Settings: Turn around 0-1000 polls. delay (ms) Maple Systems Inc., 808 134th Street SW, Suite 120, Everett, WA 98204-7333 • www.maplesystems.com 1036-0145 Page 5 of 6 Rev. 02, 08/28/2013...
- Page 6 Recommended Name Options Important Notes Settings Not Applicable Send ACK delay: 0 - 9999 Settings: Parameter 1: Not Applicable 0 - 9999 Settings: Parameter 2: Not Applicable 0 - 9999 Settings: Parameter 3: Not Applicable Interval of block pack 0-512 (words): Max.
