C O N T R O L L E R
Maple Model(s)
HMI5000 Series
Summary
Maple Systems' HMI5000 Series Human/Machine Interface Terminals (Maple HMIs)
communicate with Yaskawa Controllers using the Yaskawa XW protocol. When configured with
EZware-5000, the Maple HMI is the master in a point-to-point single-master, single-slave format.
Please refer to the Installation and Operations Manual for information on how to connect multiple
Maple HMIs to a single controller.
Compatible Controllers
Family
FSP
Communications Cable
The Maple HMI should be connected directly to the CN3 port on the
communications cables offered by Maple Systems as well as cable assembly instructions to assist
you in assembling your own communications cable are available on our website at
www.maplesystems.com.
WARNING If your communications cable is not wired exactly as shown in our cable
assembly instructions, damage to the HMI or loss of communications can
result.
Maple Systems Inc., 808 134th Street SW, Suite 120, Everett, WA 98204-7333 - www.maplesystems.com
1036-0112
I N F O R M A T I O N
PLC or Controller
Yaskawa FSP
Model
All
Page 1 of 5
S H E E T
controller.
A list of
Rev. 02, 04/30/2011
