Maple Systems HMI5000 Series Information Sheet page 4

Name
Settings: IP Address:
Settings: Port
Settings: Timeout
(sec)
Settings: Turn around
delay (ms):
Settings: Send ACK
Delay :
Settings: Parameter 1: 0
Settings: Parameter 2: 0
Settings: Parameter 3: 0
Setting: Use UDP:
PLC default station
no.:
Interval of Block Pack
(words):
Max. read-command
size (words):
Max. write-command
size (words):
Phone: 425/745-3229 • Fax: 425/745-3429 • Email: support@maplesystems.com • www.maplesystems.com
1036-0204
Recommended
Options
Settings
0.0.0.0-
xxx.xxx.xxx.xxx
255.255.255.255
9600 0-65535
1 0.1 to 25.5
0 0-1000
0
Checked or
Unchecked
Unchecked
0 0-255
0-512
5
256
256
Page 4 of 4
Important Notes
Must match the controller
port's IP Address
Must be 9600.
Adjust if longer timeout is
required
Timeout period between OIT
polls
Not Applicable
Not Applicable
Not Applicable
Not Applicable
Must be unchecked.
Must match the controller's
setting.
Not Adjustable
Not Adjustable
Rev. 01, 12/03/2013
