Accessible PLC Memory
Register Memory
The following table lists the PLC's register memory ranges that the Maple HMIs are able to
access. Please note that your PLC's memory range may be smaller or larger than that
supported by these HMIs. The following register memory can be displayed in 16 or 32-bit
format on the Maple HMI.
PLC Register Type Address Range Format
CIO
W
H
A
C
T
D
EM0-EMC
Discrete Memory
The following table lists the PLC's discrete memory ranges that the Maple HMIs are able to
access. Please note that your PLC's memory range may be smaller or larger than that
supported by these HMIs.
on the Maple HMI.
PLC Bit Type
CIO_Bit
W_Bit
H_Bit
A_Bit
D_Bit
T_Bit
C_Bit
C_Flag
T_Flag
Phone: 425/745-3229 • Fax: 425/745-3429 • Email: support@maplesystems.com • www.maplesystems.com
1036-0204
(Note: d=decimal )
0-32767
ddddd
0-32767
ddddd
0-32767
ddddd
0-32767
ddddd
0-32767
ddddd
0-32767
ddddd
0-32767
ddddd
0-32767
ddddd
The following discrete memory is displayable in single-bit format
(Note: d=decimal, b=bit)
Address Range Format
000-3276715
dddddbb
000-3276715
dddddbb
000-3276715
dddddbb
000-3276715
dddddbb
000-3276715
dddddbb
000-3276715
dddddbb
000-3276715
dddddbb
0-4095
dddd
0-4095
dddd
Page 2 of 4
PLC Register Description
Channel I/O
Work Area
Holding Area
Auxiliary Relay (Read Only)
Counter
Timer
Data Memory
Extended Memory (this
Extended Memory resides in the
PLC, and is different than the
HMI's EM areas)
PLC Bit Description
Channel I/O
Work Area
Holding Area
Auxiliary Relay (Read Only)
Counter
Timer
Data Memory
Counter Flag
Timer Flag
Rev. 01, 12/03/2013
