Maple Systems HMI5000 Series Information Sheet page 3

Important Memory Considerations
If your PLC's memory range is smaller than the range supported by the Maple HMIs, it is possible
to configure the HMI to monitor a PLC memory address that does not exist. This can cause
unpredictable results. When you configure the HMI please ensure that all selected PLC memory
addresses are valid for your PLC model.
Do not configure the HMI to write to any PLC memory address that should only be written to
by the PLC.
EZware Settings
The following table lists the communications settings that must be configured in
EZware. These settings can be found in the Edit-Set System Parameters menu under
the Device tab. Please note:

The Recommended Settings column provides the recommended setting
based upon the default settings most commonly used in the
devices.
 The Options column lists EZware's options; your PLC may not support
every option
Name
Name:
HMI or PLC
Location
PLC type:
PLC I/F:
Maple Systems Inc., 808 134th Street SW, Suite 120, Everett, WA 98204-7333
.
1036-0204
Recommended
Options
Settings
Omron
(Ethernet –
FINS/TCP)
PLC
Local Local, Remote
Omron
(Ethernet –
FINS/TCP)
Ethernet Ethernet
Page 3 of 4
Omron
Important Notes
Description label
Select Local if PLC directly
connected to HMI, Remote
if PLC connected thru
another HMI
Rev. 01, 12/03/2013
