Maple Systems HMI5000 Series Information Sheet page 5

Name
Settings: Parity:
Settings: Timeout (sec):
Settings: Turn around
delay (ms):
Settings: Parameter 1:
Settings: Parameter 2:
Settings: Parameter 3:
Interval of block pack
(words):
Max. read-command
size (words):
Max. write command
size (words):
Maple Systems Inc., 808 134th Street SW, Suite 120, Everett, WA 98204-7333 - www.maplesystems.com
1036-0112
Recommended
Options
Settings
Even, Odd, None
Even
0.1 – 25.5
3.0
0-1000
0
0
0
0
5 0-512
32
32
Page 5 of 5
Important Notes
Must match the controller port
setting.
Adjust if longer timeout required.
Timeout period between HMI polls.
Not Applicable
Not Applicable
Not Applicable
See HMI5000 Series
Programming Manual
(Maple p/n 1010-1007)
Not Adjustable
Not Adjustable
Rev. 02, 04/30/2011
