EZware Settings
The following table lists the communications settings that must be configured in
EZware. These settings can be found in the Edit-Set System Parameters menu under
the Device tab. Please note:

The Recommended Settings column provides the recommended setting based
upon the default settings most commonly used in Yaskawa devices.
 The Options column lists EZware's options; your PLC may not support every
option
Name
Name:
HMI or PLC:
Location:
PLC type:
PLC I/F:
PLC default station
no.:
Settings: COM:
Settings: Baud rate:
Settings: Data Bits
Settings: Stop bits
Phone: 425/745-3229 • Fax: 425/745-3429 • Email: support@maplesystems.com • www.maplesystems.com
1036-0112
Recommended
Options
Settings
Yaskawa FSP
PLC
Local Local, Remote
Yaskawa FSP
RS-232,
RS-485 2W,
RS-485 4W,
RS-232
Ethernet
0 0-255
COM1 – COM3
COM1
9600, 19200, 38400,
19200
57600, 115200
7 7 or 8
1 1 or 2
Page 4 of 5
Important Notes
Description label
Select Local if the PLC is
directly connected to the HMI;
Remote if the PLC is connected
thru another HMI.
Must match the controller's port
setting.
Must match the controller's Axis
setting, or use 0.
Serial port of the HMI connected to
the controller.
Must match the controller port
setting. Use the fastest baud rate
supported by the controller.
Must match the controller port
setting.
Must match the controller port
setting.
Rev. 02, 04/30/2011
