Translating from terminal mode to XML

Translating commands
The XML commands maintain the same structure as the terminal
commands, but they use a parent-child relationship to describe
the hierarchy. You can see this structure in the examples below.
example 1: Setting up a call.
Terminal
xCommand Dial Number: "12345" Protocol: H323
XML
<Command>
<Dial command="True">
<Number>12345</Number>
<Protocol>H323</Protocol>
</Dial>
</Command>
example 2: Assigning video layout to a call.
Terminal
xCommand Video Layout AssignCall CallId: 2
LayoutId: 1
XML
<Command>
<Video>
<Layout>
<AssignCall command="True">
<CallId>2</CallId>
<LayoutId>1</LayoutId>
</AssignCall>
</Layout>
</Video>
</Command>
Codec C20 API Reference Guide TC6.0 February 2013.
D14869.05
About the API About the API xConfiguration
Translating configurations
Translating from xConfiguration to XML is similar to commands,
but with the addition of a special attribute item="NN" for speci-
fying the index in arrays.
example: Configuring connector for input source 2.
Terminal
xConfiguration Video Input Source 2
Connector: HDMI
XML
<Configuration>
<Video>
<Input>
<Source item="2">
<Connector>HDMI</Connector>
</Source>
</Input>
</Video>
</Configuration>
23
