events

Event returns information about the events that are available
for feedback. This overview presents examples of some the
events that are available on the API.
To get an overview of the supported events type ?,
after xEvent:
• xEvent ? Lists the top level events
• xEvent ?? List all of the available events
• xEvent help Lists the top level events
The result for events depends on the state of the codec.
Codec C20 API Reference Guide TC6.0 February 2013.
D14869.05
About the API About the API
example 1: Outgoing Call Indication
Outgoing Call Indication is an event reported when an outgo-
ing call is about to be dialled. Returns the CallId the call has
?? or help
been assigned.
*e OutgoingCallIndication CallId: x
** end
example 2: Call Disconnect
Call Disconnect is an event reported when a call is disconnected.
Returns the CallId of the disconnected call and reason for the
call's disconnection.
*e CallDisconnect CallId: x CauseValue: 0
CauseString: "" CauseType: LocalDisconnect
OrigCallDirection: "outgoing"
** end
xConfiguration xCommand
17
API Reference Guide
xStatus
example 3: Call Successful
Call Succesful is an event reported when a call is connected
successfully, that is when all channels are up and established.
*e CallSuccessful CallId: 132 Protocol: "h223"
Direction: "outgoing" CallRate: 768 RemoteURI:
"h223:integratorHQ@company.com" EncryptionIn:
"Off" EncryptionOut: "Off"
** end
example 4: FeCC Action request
FECC Action request is an event reported when far end is
sending FECC commands.
*e FeccActionInd Id: 132 Req: 1 Pan: 1 PanRight:
1 Tilt: 0 TiltUp: 0 Zoom: 0 ZoomIn: 0 Focus: 0
FocusIn: 0 Timeout: 300 VideoSrc: 0 m: 0
** end
