Status

A status contains the current state of the codec, such as connected
calls, the status of the gatekeeper registration, connected inputs
and output sources.
Writing xStatus ? on the command line lists all top level statuses.
Writing xStatus lists all statuses and their current values.
To list out only some of the statuses, write xstatus followed by
the relevant part of the status path.
Codec C20 API Reference Guide TC6.0 February 2013.
D14869.05
About the API About the API xConfiguration
xStatus ?
– Status –
Audio
Call[...]
Camera
Conference
Diagnostics
Experimental
H320
OK
Addressing status information with xStatus
To read the status from the system type the root command (xStatus) followed by a path (address expression):
xStatus <address expression>
Example 1: Query all ongoing Call information:
xStatus Call
*s Call 3 Status: Connected
*s Call 3 Direction: Outgoing
*s Call 3 Protocol: "sip"
*s Call 3 RemoteNumber: "firstname.lastname@company.com"
*s Call 3 CallbackNumber: "sip:firstname.lastname@company.com"
*s Call 3 DisplayName: "firstname.lastname@company.com"
*s Call 3 TransmitCallRate: 768
*s Call 3 ReceiveCallRate: 768
*s Call 3 FacilityServiceId: 0
*s Call 3 Encryption Type: "None"
*s Call 3 PlacedOnHold: False
*s Call 3 Duration: 9
** end
OK
Example 2: Query the protocol for a call:
xStatus Call Protocol
*s Call 3 Protocol: "sip"
OK
16
xCommand xStatus
H323
HttpFeedback[1..4]
MediaChannels
Network
Preset[1..15]
Provisioning
Security
Copyright © 2010–2013 Cisco Systems, Inc. All rights reserved.
API Reference Guide
Appendices
SIP
Standby
SystemUnit
Time
Video
