INSTRUMENT AND CONTROL FUNCTIONS
1

Brake lever

2
3
4
5
1. Brake lever
6
The brake lever is located on the right
side of the handlebar. To apply the front
7
brake, pull the lever toward the throttle
grip.
8
9
10
11
12
EAU12892

Brake pedal

1
1. Brake pedal
The brake pedal is located on the right
side of the motorcycle. To apply the
rear brake, press down on the brake
pedal.
EAU12943

Fuel tank cap

To remove the fuel tank cap
1
1. Open the fuel tank cap lock cover.
2. Insert the key into the lock and turn
1. Fuel tank cap lock cover
2. Unlock.
To install the fuel tank cap
1. Push and install the fuel tank cap
2. Turn the key counterclockwise to
4-7
it 1/4 turn clockwise. The lock will
be released and the fuel tank cap
can be removed.
2
into position with the key inserted
in the lock.
the original position, and then re-
move it.
EAUM1794
