Engine Oil And Oil Filter Element - Yamaha XT250L 2014 Owner's Manual

PERIODIC MAINTENANCE AND ADJUSTMENT
1
Engine oil and oil filter
element
2
The engine oil level should be checked
before each ride. In addition, the oil
must be changed and the oil filter ele-
3
ment replaced at the intervals specified
in the General periodic maintenance
4
and lubrication chart.
To check the engine oil level
5
1. Place the vehicle on a level sur-
face and hold it in an upright posi-
6
tion. A slight tilt to the side can
result in a false reading.
7
2. Start the engine, warm it up for
several minutes, and then turn it
off.
8
3. Wait a few minutes until the oil set-
tles, and then check the oil level
9
through the check window located
at the bottom-right side of the
10
crankcase.
TIP
11
The engine oil should be between the
minimum and maximum level marks.
12
EAU37806
1
2
1. Maximum level mark
2. Minimum level mark
3. Engine oil level check window
4. If the engine oil is below the mini-
mum level mark, add sufficient oil
of the recommended type to raise
it to the correct level.
To change the engine oil (with or
without oil filter element replace-
ment)
1. Place the vehicle on a level sur-
face.
2. Start the engine, warm it up for
several minutes, and then turn it
off.
3. Place an oil pan under the engine
to collect the used oil.
7-12
4. Remove the engine oil filler bolt,
engine oil drain bolt and its gasket
to drain the oil from the crankcase.
1
3
1. Engine oil filler bolt
2
1
1. Engine oil drain bolt
2. Gasket
5. Remove the oil filter element drain
bolt to drain the oil from the oil filter
1
