ADV7619 Reference Manual
2.1.2 720p, 1080i and 1080p Resolutions up to a 36-bit color depth
The following settings are required for the 720p, 1080i, 1080p resolutions with color depths between 24-bit and 36-bit. For these resolutions,
the data is processed through the CP core.
2.2 INPUT VIDEO PIXEL CLOCK FREQUENCY > 170MHZ
The following settings are required for input video resolutions with a pixel clock of greater than170 MHz. For these resolutions, the CP core of
ADV7619 is bypassed and the clock divider and the double wide (48-bit) output interface are employed.
CP Map and HDMI Map
44 6C 00
68 C0 03
68 03 98
68 10 A5
68 1B 08
68 45 04
68 97 C0
68 3D 10
68 3E 69
68 3F 46
68 4E FE
68 4F 08
68 50 00
68 57 A3
68 58 07
68 6F 08
68 84 03
IO Map, DPLL Map and HDMI Map
98 00 19
98 01 05
98 DD 00
98 E7 04
4C C3 80
4C CF 03
4C DB 80
68 C0 03
68 03 98
68 10 A5
68 1B 00
68 45 04
68 97 C0
68 3E 69
68 3F 46
68 4E FE
68 4F 08
68 50 00
68 57 A3
68 58 07
68 6F 08
68 84 03
ADV7619 Required Settings Manual
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
Set VID_STD for 2x1 mode
Set PRIM_MODE for HDMI Comp
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
ADI Required Write
Rev. 1.8 | Page 6 of 14
