The ADV7619 includes the following programmable I2C map addresses:
I C Addresses
2
98 F4 80
98 F5 7C
98 F8 4C
98 F9 64
98 FA 6C
98 FB 68
98 FD 44
The I C addresses are programmed in the IO Map at the registers shown above.
2
The ADV7619 IO I C Map address is non-programmable and its address is fixed to 0x98. This address can be changed by pulling up the
2
VS/ALSB/FIELD pin with a 10k resistor and sending the SAMPLE_ALSB command (IO Map, Register 0x1B[0]). Refer to UG-237: ADV7619
Reference Manual for further information.
The I C map addresses listed above are used throughout this document.
2
CEC Map Address set to 0x80
Infoframe Map Address set to 0x7C
DPLL Map Address set to 0x4C
Repeater Map Address set to 0x64
EDID Map Address set to 0x6C
HDMI Map Address set to 0x68
CP Map Address set to 0x44
