OVERVIEW

MM200 order codes

Base
MM200
MM200
Control panel
Power supply
Communications
Protection
NOTE:

Example of an MM200 order code

1–6
The information to specify an MM200 relay is provided in the following order code figure.
Figure 1-3: MM200 order codes
* X * * *
Description (7 inputs, 2 Form A, 1 Form C, 3 CT, CBCT,
Thermistor)
| | | |
MM200 Motor Management System
X | | |
No Control Panel
B | | |
Basic Control Panel, no USB
G | | |
Graphical control panel with USB
H | |
6 AC Digital inputs 65 to 300 V AC, 3 Outputs (2 form A, 1
| |
form C), 3CT, CBCT, thermistor
L | |
7 DC digital inputs 24 V DC, 3 Outputs (2 form A, 1 form C),
| |
3CT, CBCT, thermistor
1 |
RS485 Modbus RTU plus DeviceNet Slave
2 |
RS485 plus Profibus DP slave
S |
Standard Communications: RS485 Modbus RTU
S
Standard Protection and Control
Harsh Environment Coating is a standard feature on all MM200 units.
MM200-BXL1S: MM200 with basic control panel, 24 V DC power supply, RS485 Modbus
RTU communications, three-phase current, thermal overload, undercurrent, Devicenet
communications, protection option.
