CHAPTER 1: INTRODUCTION
Ease of use
• Graphical interface
• Self-description
Mounting options
• DIN Rail
• Through door
Integrated functionality
• Protection, metering, control
MM200 MOTOR MANAGEMENT SYSTEM – INSTRUCTION MANUAL
Table 1-1: MM200 protection functions
ANSI device
37
46
49
50G
51R
Figure 1-2: MM200 feature overview
Graphical display
• Large metering values
• Wide viewing angle
Soft key navigation
• Graphical module control
Description
Undercurrent
Current unbalance
Thermal overload
Ground instantaneous overcurrent
Locked/stalled rotor, mechanical jam
LED indication
• Motor status
• Alarm indication
• System status
• Communication status
• Additional user LEDs
Front port access
• USB for laptop connection
OVERVIEW
Entry Level Control Panel
• Control keys
• LED Indication
Front panel control
• Integrated device control
• Dedicated control keys
888755A1.CDR
1–5
