PART NAMES

FRONT
BACK
15
1
Main Unit
2
Air Outlet
OFF TIMER Button / OFF TIMER indicator Light (green)
3
LIGHT ON/OFF Button (Press 3 sec.)
MODE Button / MODE Indicator Light (green)
4
Plasmacluster Ion ON/OFF Button(Press 3 sec.)
CLEAN ION SHOWER Button /
5
CLEAN ION SHOWER indicator Light (green)
6
POWER ON/OFF Button
7
ODOR sensor
8
DUST AND ODOR SIGN
9
PLASMACLUSTER SIGN
OM_FP-G50J_EN.indd
4
2
1
9
PLASMACLUSTER SIGN
blue
Plasmacluster ON
off
Plasmacluster OFF
12
13
14
16
18
E-4
3
4
5
8
DUST AND ODOR SIGN
Indicates the air purity of the room
in 3 levels with color changes.
Green
Orange
Red
10
11
19
17
(Shape of plug depends on country.)
10
11
12
13
14
15
16
17
18
19
6
7
Clean
Impure
Handle
Dust Sensor /
Dust Sensor Filter
HEPA Filter
Deodorizing Filter
Upper Tabs
Back Panel (Pre-Filter)
Bottom Tabs
Power Cord
Plug
Date Label
2017/01/10
16:47:18
