Sharp FP-J40E Operation Manual

Hide thumbs

Advertisement

Quick Links

FP-J40E
FP-J40L
FP-J40M
"Plasmacluster" and "Device of a cluster of grapes"
are registered trademarks of Sharp Corporation in
Japan, Philippines and elsewhere.
*The number in this technology mark indicates an
approximate number of ions supplied into air of 1 cm
which is measured around the center of a room with
the "high-density plasmacluster 7000" applicable floor
area (at 1.2 m height above the floor) at the medium
wind volume in air purifying mode, when an air purifier
using the high-density plasmacluster ion evolving
device is placed close to a wall. This product is
equipped with a device corresponding to this capacity.
Free standing type
Jenis berdiri sendiri
Kiểu máy có chân tự đứng
站立式
OM_FP-J40E_40L_EN.indd
1
R
,
3
AIR PURIFIER
OPERATION MANUAL
PEMBERSIH UDARA
BUKU PANDUAN OPERASI
HƯỚNG DẪN SỬ DỤNG MÁY
NĂNG BẮT MUỖI
空气净化器操作手册
2018/06/25
11:42:52

Advertisement

loading

  Summary of Contents for Sharp FP-J40E

  • Page 1 NĂNG BẮT MUỖI 空气净化器操作手册 “Plasmacluster” and “Device of a cluster of grapes” are registered trademarks of Sharp Corporation in Japan, Philippines and elsewhere. *The number in this technology mark indicates an approximate number of ions supplied into air of 1 cm which is measured around the center of a room with the “high-density plasmacluster 7000”...
  • Page 2 Please read before operating your new Air Purifier The air purifier draws in room air from the air intake, passes the air through a Pre-Filter, a Deodorizing Filter and a HEPA Filter inside of the main unit, then discharges the air through the air outlet.
  • Page 3: Table Of Contents

    Sensor Technology continuously monitors air quality, and automatically adjusting operation based on detected air purity. Thank you for purchasing the SHARP Air Purifier. Please read this manual carefully. Before using this product, be sure to read the section: “Important Safety Instructions.”...
  • Page 4: Important Safety Instructions

    Electrical shock and/or fire from a short circuit may result. • If the power cord is damaged, it must be replaced by the manufacturer, its service agent, Sharp Approved Service Center or similarly qualified person in order to avoid a hazard.
  • Page 5 CAUTIONS CONCERNING OPERATION • Do not block the intake and/or air outlet. • Do not use the unit near or on hot objects, such as stoves or heaters or where it may come into contact with steam. • Do not lay the unit down when using. •...
  • Page 6: Part Names

    PART NAMES FRONT Cleanliness Monitor Blue Clean Indicates the air purity of the room in 3 levels with color changes. Orange Impure BACK Main Unit Cleanliness Monitor Air Outlet Handle Dust Sensor Filter OFF TIMER Button, Indicator Light (white) (Press 3 sec.) Filter Reset Button, Indicator Light (orange) HEPA Filter Deodorizing Filter MODE Button, Indicator Light (white)
  • Page 7: Filter Installation

    FILTER INSTALLATION Be sure to remove the power plug from the wall outlet. To maintain the quality of the fi lter, it is installed in the main unit and packed in plastic bag. Be sure to the remove plastic bag from the fi lter before using the unit. Place the Filter within the main unit.
  • Page 8: Operation

    OPERATION START/STOP START STOP • Select the desired fan speed. •When the main unit starts operation, the operation starts in the previous mode it was operated in. HAZE The unit operates at HIGH fan speed for 60 minutes and then alternates between Low and High level for 20 minutes each.
  • Page 9 Light Control You can set the Cleanliness Monitor / Plasmaclustor Ion Light to OFF when their SIGN is bright. (with the main unit ON) NOTE • When the main unit starts operation, the operation starts in the previous mode it more than 3 sec.
  • Page 10: Care And Maintenance

    CARE AND MAINTENANCE Be sure to remove the power plug from the wall outlet. To maintain optimum performance of this air purifi er, please clean the unit including the fi lter periodically. Be sure to disconnect the power cord from the wall outlet before performing any maintenance. BACK PANEL (Pre-fi lter) Gently remove dust from the back panel, using a vacuum cleaner...
  • Page 11: Replacement

    UNIT Wipe with a dry, soft cloth For stubborn stains or dirt, use a soft cloth dampened with warm water. CAUTION •Do not use volatile fluids Benzine, paint thinner, polishing powder, etc., may damage the surface. •Do not use detergents Detergent ingredients may damage the unit.
  • Page 12: Troubleshooting

    TROUBLESHOOTING Before calling for service, please review the Troubleshooting chart below, since the problem may not be a unit malfunction. SYMPTOM REMEDY (not a malfunction) Odors and smoke are not removed. • Replace the filters if they appear to be heavily soiled. (page 9) The Cleanliness Monitor illuminates blue •...
  • Page 13: Specifications

    SPECIFICATIONS Power supply 220-240V 50-60Hz SLEEP *1 Fan Speed Adjustment Speed Rated Power 4.0~7.0W Operation Fan Speed 240m /hour 186m /hour 48~120m /hour Recommended Room Size ~30m High density Plasmacluster ion recommended room size ~23m Cord Length 2.0m Dimensions 390mm(W)x270mm(D)x583mm(H) Weight 6.2kg *1 The fan speed is automatically switched depending on the amount of impurities in the air.
  • Page 14 SHARP CORPORATION OSAKA, JAPAN Printed in Thailand TINS-B147KKRZ 18G- OM_FP-J40E_40L_EN.indd 2018/06/25 11:44:42...

This manual is also suitable for:

Fp-j40lFp-j40m
