Rear Panel Ports and Slots

The ports and slots on the rear of the system unit are shown in Figure 1-3 and described
in Table 1-3.
Figure 1–3: Rear Panel Ports and Slots
2 3
5 6
4
7 8 9
AlphaServer 1000 Rackmount Owner's Guide 1-9
System Overview
1
1. Four additional SCSI
port knockouts
2. VGA port
3. Keyboard port
4. Serial port/terminal
port
(COM1)
5. External SCSI port
6. Mouse port
7. Serial port/terminal
port (COM2)
10
8. Parallel port
MLO-011547
9. PCI/EISA
10. Power inlet
