For Residential and Commercial Use
SSP Models
This manual must only be used by a qualified installer / service technician. Read all instructions in this manual before installing.
Perform steps in the given order. Failure to do so could result in substantial property damage, severe personal injury, or death.
California Proposition 65 Warning: This product contains chemicals known to the State of California to cause cancer, birth
defects, or other reproductive harm.
HTP reserves the right to make product changes or updates without notice and will not be held liable for typographical errors
in literature.
The surfaces of these products contacted by potable (consumable) water contain less than 0.25% lead by weight as required
by the Safe Drinking Water Act, Section 1417.
NOTE TO CONSUMER: PLEASE KEEP ALL INSTRUCTIONS FOR FUTURE REFERENCE.
272 Duchaine Blvd.
S uperstor Pro
Indirect Fired

Water Heaters

New Bedford, MA 02745
www.htproducts.com
lp-451 Rev. 001 Rel. 001 Date 7.25.17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Superstor Pro 30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HTP Superstor Pro 30

Summary of Contents for HTP Superstor Pro 30

  • Page 1: Water Heaters

    California Proposition 65 Warning: This product contains chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. HTP reserves the right to make product changes or updates without notice and will not be held liable for typographical errors in literature.

  • Page 2: Table Of Contents

    AHJ. Perform steps in the given order. NOTE: HTP reserves the right to modify product technical specifications User - This manual is for use only by a qualified heating installer and components without prior notice.

  • Page 3: Property Damage

    High heat sources (sources generating heat 100 F / 37 C or In water heaters with single wall heat exchangers, the heat transfer greater, such as stove pipes, space heaters, etc.) may damage fluid must be water or nontoxic food grade glycol, FDA rated plastic components of the water heater as well as plastic vent “generally recognized as safe”...

  • Page 4: Water Chemistry Requirements

    Choose a location for the water heater as centralized to the piping system as possible. Also, locate the water heater and domestic water RECOMMENDED SERVICE CLEARANCES piping where it will not be exposed to freezing temperatures. All ZERO CLEARANCE piping should be insulated. Additionally, place the water heater so that the drain, controls, and inlets/outlets are easily accessible.
  • Page 5 VIEW AUX/RECIRC INLET OUTLET RELIEF THERMOSTAT VALVE ACCESS COVER THERMOSTAT CONNECTION BOILER IN BOILER IN BOILER OUT BOILER OUT DRAIN VALVE 30 MODEL 40 / 50 / 60 / 80 / 100 MODELS INDIRECT WATER HEATER CAPACITY DOMESTIC MODEL U.S. GAL. CONNECTION 42-1/8"...

  • Page 6: Part 3 - Piping

    Part 3 - Piping A. Plumbing It is mandatory that all plumbing be done in accordance with federal, Never connect auxiliary connections to any system that uses glycol local, and state plumbing codes and practices. Failure to properly or other solutions formulated for hydronic systems. These auxiliary install the water heater WILL VOID the warranty.

  • Page 7: Scalding

    This water heater can deliver scalding water. Be careful whenever using RE-INSPECTION OF T&P RELIEF VALVES: T&P valves should be hot water to avoid scalding inspected AT LEAST ONCE EVERY THREE YEARS, and replaced if injury. Certain appliances necessary, by a licensed plumbing contractor or qualified service such as dishwashers and technician to ensure that the product has not been affected by automatic clothes washers...

  • Page 8: Applications

    I. Applications ZONE RETURN SWING CHECK VALVE COLD WATER SUPPLY ZONE VALVE MIXING VALVE HOT WATER OUTLET IT IS RECOMMENDED THAT 1" LINES AND 1" ZONE VALVES ARE USED FOR INDIRECT WATER HEATER ZONE TEMPERATURE/PRESSURE RELIEF VALVE BOILER BOILER LP-451-B CIRCULATOR 03/29/17 LP-451-C...

  • Page 9: Part 4 - Heater Control And Wiring

    Part 4 - Heater Control and Wiring A. Control A surface mount thermostatic control has been provided for accurate temperature adjustment. B. Wiring Wiring is to be done in accordance with all applicable local and state codes. Turn off all power related to the boiler before starting any wiring procedures.

  • Page 10: Part 5 - Start-Up And Operation

    Part 5 - Start-Up and Operation 1. Fill the water heater by opening the cold water shut-off valve. Make certain the field installed drain valve is completely closed. Purge air from the system by opening a hot water outlet at a fixture in a kitchen or bathroom.

  • Page 11: Part 6 - Maintenance And Troubleshooting

    Part 6 - Maintenance and Troubleshooting Periodic maintenance should be performed by a qualified service heating contractor for periodic maintenance of the heater. Installer technician to ensure all equipment is operating safely and efficiently. must also inform the owner that the lack of proper water heater care The owner should make necessary arrangements with a qualified and maintenance may result in hazardous conditions.

  • Page 12: Troubleshooting

    Troubleshooting No Hot Water Not Enough Hot Water Problem Possible Solution Problem Possible Solution Zone valve not opening Open manually to replace Zone valve restriction 1” full bore replace zone valve Circulator not operating Check or replace Circulator arrow reversed Reverse circulator Tank control set too low Raise tank temperature*...

  • Page 13: Limited Warranty

    Standard Residential Use shall mean water heaters not registered prone to vacuum related damages. online with HTP used in a single family dwelling, or usage in a 3. Maintain the water heater in accordance with the maintenance multiple family dwelling, provided that the water heater services procedure listed in the manufacturer’s provided instructions.
  • Page 14 NOTE: Any components or heaters returned to HTP for warranty analysis will become the property of HTP and will not be returned, even if credit is denied. If all warranty conditions are satisfied, HTP will provide replacement components to the retailer.

  • Page 15: Customer Installation Record Form

    Customer Installation Record Form The following form should be completed by the installer for you to keep as a record of the installation in case of a warranty claim. After reading the important notes at the bottom of the page, please also sign this document. Customer’s Name Date of Installation Installation Address...

This manual is also suitable for:

Superstor pro 80Superstor pro 100Superstor pro 40Superstor pro 50Superstor pro 60
