Service Manual
HYDRA SMART RESIDENTIAL WATER HEATER
Advanced Heating
& Hot Water Systems
120 Braley Road, East Freetown, MA 02717
•
1-800-323-9651
•
www.htproducts.com
LP-532 REV. 8.13.2014
Hydra Smart Residential Water Heater
Service Manual
Model
RT-199
• Natural Gas ( NG ) – Factory Default
• Liquid Propane Gas ( LP ) – Contact Factory
WARNING
If the information in these instructions is not followed exactly, a fire or explosion may result,
causing property damage, personal injury, or death.
– Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS
· Do not try to light any appliance.
· Do not touch any electrical switch; do not use any phone in your building.
· Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
· If you cannot reach your gas supplier, call the fire department.
– Installation and service must be performed by a qualified installer, service agency or the gas supplier.
LP-532 REV. 8.13.2014
(Residential Water Heater)
SCAQMD Rule 1146.2
SCAQMD Rule 1146.2
