HTP PIONEER Instructions

DIRECT FIRED WATER HEATER CONVERSION
INSTRUCTIONS FOR PROPANE OR NATURAL GAS
(PIONEER, VERSA-FLAME, VERSA-HYDRO, PHOENIX, PHOENIX PLUS)
STOP! Follow these instructions or warranty will be void!
This conversion shall be done by a qualified service agency in accordance with these instructions, all applicable codes,
and requirements of the authority having jurisdiction. If the information in these instructions is not followed exactly, a fire,
explosion, or production of carbon monoxide may result in substantial property damage, severe personal injury, or death.
INSTALLATION MUST COMPLY WITH:
1. National Electrical Code.
2. The latest version of the National Fuel Gas Code, ANSI
Z223.1.
3. In Canada, CSA C22.1 Canadian Electrical Code Part 1, and
CGA No. B149 (latest version).
4. Local, state, provincial, and national codes, laws, regulations,
and ordinances.
ITEMS NEEDED FOR CONVERSION
INCLUDED IN KIT

(1) Transparent Conversion Tag

(1) Appliance Conversion Date Label

(1) Plastic Gas ID Tag with (2) Self-Tapping #4 x ¾"
Screws to mount to the Outer Jacket Plastic Cabinet

U.L. Approved High Temperature Metal Foil Tape
(included)
TOOLS REQUIRED (NOT INCLUDED)

Flat head screwdriver

CO tester for combustion readings

2mm and 4mm Allen keys
These instructions are for the conversion of Direct Fired Heater
Models with the Dungs Gas Valve. Please make sure that the
model you are converting has the Dungs Gas Valve. (See Figure
1 for verification.)
STEP 1: PREPARATION
Turn off all electrical power to the heater. Shut off the gas with
the manual shutoff before beginning the conversion. Make sure
that you are properly connected to the gas supply. Check the gas
piping and pressure to assure proper sizing for the heater firing
rate. It is recommended that you contact your gas supplier to
verify correct gas piping size and proper connection. It may also
be necessary to install a 100% lockup gas pressure regulator of
sufficient size to supply the correct pressure and gas flow.
Advanced Heating and Hot Water Systems
P.O. Box 429 ∙ 120 Braley Road ∙ East Freetown, MA 02717 ∙ 508-763-8071∙ Fax: 508-763-3769
Figure 1
LP-190 Rev. 9.30.24
