INSTRUCTION MANUAL
PETROL
7 TON VERTICAL
LOG SPLITTER
Model No: THPLS7TP -- Product No: 193877003
ASSEMBLY REQUIRED
SAVE THESE INSTRUCTIONS
SPARES & SUPPORT: 01793 333212
Read & understand operator's manual before using the machine. Failure to follow instructions could
result in death or serious injury.
The manufacturer reserves the right to change the product specification and livery according to
continued product improvements.
20-12-2016
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for The Handy THPLS7TP
Summary of Contents for The Handy THPLS7TP
-
Page 1: Log Splitter
INSTRUCTION MANUAL PETROL 7 TON VERTICAL LOG SPLITTER Model No: THPLS7TP -- Product No: 193877003 ASSEMBLY REQUIRED SAVE THESE INSTRUCTIONS SPARES & SUPPORT: 01793 333212 Read & understand operator’s manual before using the machine. Failure to follow instructions could result in death or serious injury. -
Page 3: Table Of Contents
CONTENTS SPECIFICATION IMPORTANT INFORMATION GENERAL SAFETY INSTRUCTIONS UNPACKING CONTENTS SET UP & PREPARATION FOR OPERATION OPERATION MAINTENANCE & STORAGE TROUBLE SHOOTING EC DECLARATION OF CONFORMITY PARTS LISTS & DIAGRAM WARRANTY If you require any assistance with regards to the contents or operation of your machine, please contact us: Tel: 01793 333212 - Monday to Friday 8.00am to 5.30pm (excl. -
Page 4: Specification
SPECIFICATION The manufacturer reserves the right to change the product specification and livery according to continued product improvements. Model THPLS7TP Product No. 193877003 Engine Briggs & Stratton 950 Series Splitting Force 7 Ton Hydraulic Pressure 17.8Mpa Stroke Length 475mm Forward Speed 4.9cm/sec... -
Page 5: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS It is important that you read and understand the owner’s manual and labels affixed to the machine. Learn its application and limitations as well as the specific potential hazards. Retain these instructions for future reference. The operator is responsible for following the warnings & instructions in this manual and on the product. - Page 6 STAY ALERT Do not operate the machine while under the influence of drugs, alcohol, or any medication that could affect your ability to use it properly. Do not use this machine when you are tired or distracted from the job at hand. Be aware of what you are doing at all times. Use common sense. AVOID DANGEROUS CONDITIONS Make sure there is adequate surrounding workspace.
- Page 7 PROTECT THE ENVIRONMENT Take left over materials to an authorised collection point or follow the stipulations in the country where the machine is used. Do not discharge into drains, soil or water. STORE IDLE EQUIPMENT When not in use, the machine should be stored in a dry location. Keep the machine away from children and others not qualified to use it.
-
Page 8: Set Up & Preparation For Operation
SET UP & PREPARATION FOR OPERATION Follow the below assembly instructions carefully, you should be able to assemble the machine in a short period. STEP 1 Pull Spring Pin (A) to remove Lock Pin (B). Apply a thin coat of grease to both surfaces of the Control Lever Guard as shown. - Page 9 FUEL SAFETY Fuel is highly flammable, and its vapors can explode if ignited. Take precautions when using to reduce the chance of serious personal injury. Only refill or drain the fuel tank in a clean well-ventilated outdoor area. Use an approved fuel storage container.
-
Page 10: Operation
Engine Manual packed separately with the machine. All questions related to the operation of the engine, should be directed to the Engine Manufacturer, who will supply a separate engine warranty from the Handy machine warranty. AIR BLEEDER IMPORTANT Before operating the log splitter, the Air Bleeder should be loosened a few rotations until air can go in and out of the oil tank smoothly. -
Page 11: Splitting Logs
SPLITTING LOGS Plan your work site. Work safely and save effort by planning your work beforehand. Have your logs positioned where they can be easily reached. Have an area prepared to stack the split wood. HINTS & TIPS Never attempt to load the log splitter whilst the ram is in motion. ... - Page 12 3. Open the Air Bleed. Loosen the oil tank cover a few turns whenever the splitter is being used. Retighten the cover when finished 4. Turn the engine on, the wedge ram should rise to the highest position automatically. If the wedge ram is already at the highest position when the motor starts, grip both control levers and lower them, the wedge ram should start to move downward.
-
Page 13: Maintenance & Storage
11. Stack as you work. This will provide a safer work area, keeping it uncluttered, and avoid the danger of tripping, or damaging the power cord. Accumulated split wood and wood chips can DO NOT attempt to split green logs. Dry, create a hazardous work environment. - Page 14 REPLACING THE HYDRAULIC OIL The hydraulic system is a closed system with oil tank, oil pump and control valve. Check the oil level regularly with the dipstick, located on the Air Bleeder. Low oil levels can damage the oil pump. Oil Level should measure approx.
- Page 15 WEDGE SHARPENING This log splitter is equipped with a reinforced splitting wedge. The blade is specially treated. After long periods of operation, and when required; sharpen the wedge using a fine-toothed file removing any burrs or flat spots on the edge. DIAGRAMS PLUMBING WIRING...
-
Page 16: Trouble Shooting
TROUBLE SHOOTING PROBLEM CAUSE REMEDY 1. Attach the spark plug wire securely to the spark plug. 1. Spark plug wire disconnected. 2. Fill with clean, fresh petrol. 2. Out of fuel or stale fuel. 3. Choke must be positioned to ON for a Engine fails to 3. -
Page 17: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: Petrol 7 Ton Electrical Log Splitter Model(s): THPLS7TP Product Number: 193877003 Type/Serial No: As per rating label on machine Complies with the following directives:... -
Page 18: Parts Lists & Diagram
PARTS DIAGRAM... - Page 19 PARTS LIST PART NO DESCRIPTION PART NO DESCRIPTION TH107-1GM Main Body TH107-41 CCQ Cylinder TH107-2GM Pump Guard TH107-42 Hex Bolt TH107-3 Spring Washer 6 TH107-43 Lever Handle TH107-4 Screw M6x12 TH107-44 Locknut M8 TH107-5 O-Ring 23.6x3.55G TH107-45 Pin D TH107-6 TH107-46 Operate Handle TH107-7...
- Page 20 GJ HANDY & CO LTD USER WARRANTY POLICY Users Statement of Warranty Each new machine is warranted against defective material or assembly of material under normal usage. The warranty applies to the original purchaser and covers faulty parts and the labour involved in replacing and repairing those parts, which are of original manufacture.
- Page 21 GJ HANDY & CO LTD USER WARRANTY POLICY Not covered by this warranty a) The warranty policy does not cover any depreciation or damages caused by ordinary wear, rusting or corrosion, lack of correct maintenance or operation, misuse, abuse, lack of transportation or accident.
- Page 22 NOTES _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________...
-
Page 24: Email: Customerservice@Handydistribution.co.uk
For spares or support of your Handy product, please contact us: Tel: 01793 333212 (Mon – Fri 8.00am to 5.30pm excl. Bank Holidays) Email: customerservice@handydistribution.co.uk To see our range of garden machinery & equipment visit: www.thehandy.co.uk Making gardening easier & affordable since 1938 Distributed by Handy Distribution, Murdock Road, Dorcan, Swindon, SN3 5HY...
