The Handy THLSV7 Instruction Manual

3000w electric vertical 7-ton logsplitter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL
3000W ELECTRIC
7-TON LOGSPLITTER
MODEL NO: THLSV7 -- PRODUCT NO: 1938182001
EN - ORIGINAL INSTRUCTIONS
ASSEMBLY REQUIRED – TWO PERSON
SPARES & SUPPORT: 01793 333212
Please read & understand this manual, paying attention to the safety instructions, before use.
Incorrect use of the product could put the operator or machine in danger.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, our
policy of continuous improvement determines the right to make modifications without prior warning.
VERTICAL
SAVE THESE INSTRUCTIONS
FOR YOUR SAFETY
Images used are for illustration purposes only
13-09-2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the THLSV7 and is the answer not in the manual?

Questions and answers

Related Manuals for The Handy THLSV7

Summary of Contents for The Handy THLSV7

  • Page 1 INSTRUCTION MANUAL 3000W ELECTRIC VERTICAL 7-TON LOGSPLITTER MODEL NO: THLSV7 -- PRODUCT NO: 1938182001 EN - ORIGINAL INSTRUCTIONS ASSEMBLY REQUIRED – TWO PERSON SAVE THESE INSTRUCTIONS SPARES & SUPPORT: 01793 333212 FOR YOUR SAFETY Please read & understand this manual, paying attention to the safety instructions, before use.
  • Page 2 Copyright Notice Copyright © Handy Distribution Permission is granted to reproduce this publication for personal & educational use only. Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Handy Distribution.

  • Page 3: Table Of Contents

    CONTENTS SPECIFICATIONS IMPORTANT INFORMATION GENERAL SAFETY INSTRUCTIONS SET UP & PREPARATION FOR OPERATION KNOW YOUR MACHINE OPERATION CHECKING & REPLACING HYDRAULIC OIL TROUBLE SHOOTING MAINTENANCE & STORAGE WIRING & HYDRAULIC SYSTEM DIAGRAMS EC DECLARATION OF CONFORMITY PARTS DIAGRAM & LIST WARRANTY NOTES ASSEMBLY IS REQUIRED –...

  • Page 4: Specifications

    SPECIFICATIONS The manufacturer reserves the right to change the product specification and livery according to continued product improvements. Model Number THLSV7 Product Number 1938182001 Motor* (230V ~50Hz 13A) 3000W, S6 40%, Splitting Force 7 Ton Forward Speed 3.6 cm/s Retract Speed 16.5 cm/s...

  • Page 5: General Safety Instructions

    GENERAL SAFETY INSTRUCTIONS It is important that you read and understand the owner’s manual and labels affixed to the machine. Learn its application and limitations as well as the specific potential hazards. Retain these instructions for future reference. The operator is responsible for following the warnings & instructions in this manual and on the product.
  • Page 6 STAY ALERT Do not operate the machine while under the influence of drugs, alcohol, or any medication that could affect your ability to use it properly. Do not use this machine when you are tired or distracted from the job at hand. Be aware of what you are doing at all times.
  • Page 7 DISCONNECT POWER Unplug when not in use, before adjusting, changing parts, cleaning, or working on the logsplitter. All servicing and repairs are recommended to be undertaken by an approved service dealer. MAINTAIN YOUR MACHINE WITH CARE Clean the machine immediately after use. Keep the machine clean to ensure it operates to its full & safest performance.

  • Page 8: Set Up & Preparation For Operation

    SET UP & PREPARATION FOR OPERATION Familiarise yourself with the assembly components of this logsplitter in the illustrations. If you believe you are missing any components, please contact us: 1. Log Splitter Frame 5. Support Table 2. Control Lever & Guard Assembly (1 pair) 6.
  • Page 9 ASSEMBLY WHEELS 1. Loosen the bolt on the wheel shaft mount bracket on the base by turning it counter- clockwise, until the wheel shaft can be inserted into the mount bracket. 2. Insert the wheel shaft into the mount bracket. 3.
  • Page 10 3. Insert the hooks of the log support table into the mount brackets. 4. Tighten the star knob. CONTROL LEVER 1. Insert a M10x25 bolt with a flat washer into the hole on the armguard. 2. Make sure the lever end goes into the square slot at the end of the armguard.
  • Page 11 ADJUSTABLE LOG HOLDER 1. Secure the log clamps on the armguards with star knobs and flat washers. Each star knob has three flat washers.

  • Page 12: Know Your Machine

    KNOW YOUR MACHINE Make yourself aware of the compnents and operational levers of the machine, prior to attempting any work.
  • Page 13 BLEED SCREW IMPORTANT Before operating the logsplitter, the Oil Filler/Air Bleed should be loosened a few rotations until air can go in and out of the oil tank smoothly. Air flow through the Oil Filler/Air Bleed hole should be noticeable while the logsplitter is working. Before moving the log splitter, ensure the Oil Filler/Air Bleed is tightened to avoid oil leaks.

  • Page 14: Operation

    OPERATION APPLICATION CONDITIONS Before operation, we recommend the machine is fixed to the machine using Bolts M10x30 (not supplied) on level ground. 1. Plan your work site. Work safely and save effort by planning your work beforehand. Have your logs positioned where they can be easily reached.
  • Page 15 • To set wedge ram stroke, take the following steps: ❖ Move splitting wedge to desired position. The upper position of the ram wedge travel should be about 3-5cm over the logs to be split. ❖ Release a control lever or switch off motor. ❖...

  • Page 16: Checking & Replacing Hydraulic Oil

    SHARPENING THE SPLITTING WEDGE This log splitter is equipped with a reinforced splitting wedge which is specially treated. After long periods of operation, and when required; sharpen the wedge using a fine-toothed file removing any burrs or flat spots on the edge.
  • Page 17 REPLACING HYDRAULIC OIL The hydraulic system is a closed system with oil tank, oil pump and control valve. Check oil level regularly with dipstick. Low oil levels can damage the oil pump. Oil Level should measure approx. 1 ~ 2 cm lower than the upper surface of the oil tank.

  • Page 18: Trouble Shooting

    TROUBLE SHOOTING PROBLEM PROBABLE CAUSE REMEDY SUGGESTED Refer to “Operation” section for perfect Log is improperly positioned log loading. The sizes or hardness of the log Reduce the log sizes before splitting it on exceeds the capacity of the Fails to split logs the log splitter.

  • Page 19: Wiring & Hydraulic System Diagrams

    WIRING & HYDRAULIC SYSTEM DIAGRAMS WIRING DIAGRAM HYDRAULIC DIAGRAM...

  • Page 20: Ec Declaration Of Conformity

    EC DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: Vertical Electric 7 Ton Log Splitter Model(s): THLSV7 Product Number: 1938182001 Type/Serial No: As per rating label on machine Motor Wattage: 3000 Complies with the following directives: 2006/42/EC –...
  • Page 21 PARTS DIAGRAM – THLSV7 (1938182001)
  • Page 22 PARTS LIST – THLSV7 (1938182001) – Pt 1 Item No Handy Part No. Description TH245-1 Side Log Support 2 TH245-2 Side Log Support 1 TH245-3 Locknut M8 TH245-4 Washer 8 TH245-5 Spring TH245-6 Bush TH245-7 Bolt 8.8 M8x210 TH245-8 Log Support G5 TH245-9 Bolt 8.8 M8x60...
  • Page 23 PARTS LIST – THLSV7 (1938182001) – Pt 2 Item No Handy Part No. Description TH199-50 Washer 20 TH199-52 Pull Rod G5 TH199-43 Washer 16 TH245-32 Lever C1 TH199-48 Tube KG TH199-55 Cylinder G5 TH199-53 Star Knob (black) TH245-33 Main Frame G5...
  • Page 24 GJ HANDY & CO LTD USER WARRANTY POLICY Users Statement of Warranty Each new machine is warranted against defective material or assembly of material under normal usage. The warranty applies to the original purchaser and covers faulty parts and the labour involved in replacing and repairing those parts, which are of original manufacture.
  • Page 25 GJ HANDY & CO LTD USER WARRANTY POLICY Not covered by this warranty a) The warranty policy does not cover any depreciation or damages caused by ordinary wear, rusting or corrosion, lack of correct maintenance or operation, misuse, abuse, lack of transportation or accident. b) The warranty policy does not cover any costs necessary for the standard periodic maintenance services instructed by the operator’s manual, or service parts replacement which would include oil, filters, tyres, belts, brake linings, fuses, blades, seals and other service parts unless it can be proven that the item has...

  • Page 26: Notes

    NOTES ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________...

  • Page 28: Tel: 01793 333212

    For spares or support of your handy product, please contact us: Tel: 01793 333212 (Mon – Fri 8.00am to 5.30pm excl. Bank Holidays) Email: customerservice@handydistribution.co.uk To see our range of garden machinery & equipment visit: www.thehandy.co.uk Making gardening easier & affordable since 1938 Distributed by Handy Distribution, Murdock Road, Dorcan, Swindon, SN3 5HY...
