OPERATOR'S MANUAL & PARTS LIST
MODEL – THFLS
FOOT OPERATED MANUAL LOG SPLITTER
Please read & understand this manual, paying particular attention to the safety
instructions, before use. Failure to follow instructions can result in personal
injury to you or bystanders.
The manufacturer reserves the right to change the product specification and livery according to continued product improvements.
193851001
07/07/2015
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for The Handy THFLS
Summary of Contents for The Handy THFLS
- Page 1 OPERATOR’S MANUAL & PARTS LIST MODEL – THFLS FOOT OPERATED MANUAL LOG SPLITTER Please read & understand this manual, paying particular attention to the safety instructions, before use. Failure to follow instructions can result in personal injury to you or bystanders.
-
Page 3: Table Of Contents
CONTENTS SPECIFICATIONS SAFETY INSTRUCTIONS OPERATING INSTRUCTIONS ASSEMBLY MAINTENANCE & STORAGE OPERATION PARTS DIAGRAM & LIST GUARANTEE... -
Page 4: Specifications
SPECIFICATIONS Model THFLS Product Number 193851001 Splitting Force 1.5 Tonnes Minimum/Maximum Log Length 100mm/420mm Maximum Log Diameter 150mm Weight 12.5kgs The manufacturer reserves the right to change the product specification and livery according to continued product improvements. -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS Read and understand the owner’s manual and labels affixed to the machine. Learn its application and limitations as well as the specific potential hazards. Retain these instructions for future reference. The operator is responsible for following the warnings & instructions in this manual and on the product. -
Page 6: Assembly
ASSEMBLY The Foot Operated Log Splitter is fully assembled at the factory. Remove the Splitter and contents from the carton. If you are unable to lift the Splitter from the carton, safely cut the end section to allow you to slide the Splitter away from the carton. -
Page 7: Maintenance & Storage
MAINTENANCE & STORAGE WARNING Improper maintenance & storage of the Splitter may void your warranty. Keep the Splitter clean for better and safer performance. MAINTENANCE Occasionally sharpen the splitting wedge. Use a file or sharpening stone (Not included). Alternatively, contact your local approved service dealer for assistance. A sharp splitting wedge will split wood safely and effectively. -
Page 8: Parts Diagram & List
PARTS DIAGRAM & LIST Item No. Part No. Description Quantity TH214-1 Slide Stop TH214-2 Log Guide TH214-3 Spacer TH214-4 Lock Nut M8 TH214-5 Nut M8 TH214-6 Spring Washer Ø8 TH214-7 Hex Bolt M8*110-1M8*70-1 TH214-8 Support Beam TH214-9 Wheel Ø125*30 TH214-10 Circlip Ø16 TH214-11 Screw Ring M8*40... - Page 9 GJ HANDY & CO LTD USER WARRANTY POLICY 1. Users Statement of Warranty Each new machine is warranted against defective material or assembly of material under normal usage. The warranty applies to the original purchaser and covers faulty parts and the labour involved in replacing and repairing those parts, which are of original manufacture.
- Page 10 GJ HANDY & CO LTD USER WARRANTY POLICY 3. Not covered by this warranty The warranty policy does not cover any depreciation or damages caused by ordinary wear, rusting or corrosion, lack of correct maintenance or operation, misuse, abuse, lack of transportation or accident.
- Page 12 For Spares or Support of your Handy product, please contact us: Tel: 01793 333212 (Mon – Fri 8.30am to 5.00pm) Email: customerservice@handydistribution.co.uk To see our complete range of garden machinery and equipment visit: www.thehandy.co.uk Distributed by Handy Distribution, Murdock Road, Dorcan, Swindon, SN3 5HY...
