INSTRUCTION MANUAL
3000W ELECTRIC
7 TON VERTICAL
LOG SPLITTER
Model No: THPLS7TE -- Product No: 1938139001
ASSEMBLY REQUIRED
SAVE THESE INSTRUCTIONS
SPARES & SUPPORT: 01793 333212
Please read & understand this manual, paying particular attention to the safety instructions,
before use.
The manufacturer reserves the right to change the product specification and livery according to
continued product improvements.
29-03-2017
Advertisement
Table of Contents
Related Manuals for The Handy THPLS7TE
Summary of Contents for The Handy THPLS7TE
-
Page 1: Log Splitter
INSTRUCTION MANUAL 3000W ELECTRIC 7 TON VERTICAL LOG SPLITTER Model No: THPLS7TE -- Product No: 1938139001 ASSEMBLY REQUIRED SAVE THESE INSTRUCTIONS SPARES & SUPPORT: 01793 333212 Please read & understand this manual, paying particular attention to the safety instructions, before use. -
Page 3: Table Of Contents
CONTENTS SPECIFICATION IMPORTANT INFORMATION GENERAL SAFETY INSTRUCTIONS UNPACKING CONTENTS SET UP & PREPARATION FOR OPERATION OPERATION MAINTENANCE & STORAGE TROUBLE SHOOTING EC DECLARATION OF CONFORMITY PARTS LISTS & DIAGRAM WARRANTY If you require any assistance with regards to the contents or operation of your machine, please contact us: Tel: 01793 333212 - Mon to Friday 8.00am to 5.30pm (excl. -
Page 4: Specification
SPECIFICATION The manufacturer reserves the right to change the product specification and livery according to continued product improvements. Model THPLS7TE Product No. 1938139001 Motor Rated Power 230V~50Hz 3000W IP54 Diameter Min. 12cm - Max. 32cm Log Size Capacity Length 104cm - 78cm - 52cm... -
Page 5: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS It is important that you read and understand the owner’s manual and labels affixed to the machine. Learn its application and limitations as well as the specific potential hazards. Retain these instructions for future reference. The operator is responsible for following the warnings & instructions in this manual and on the product. - Page 6 STAY ALERT Do not operate the machine while under the influence of drugs, alcohol, or any medication that could affect your ability to use it properly. Do not use this machine when you are tired or distracted from the job at hand. Be aware of what you are doing at all times. Use common sense. AVOID DANGEROUS CONDITIONS Make sure there is adequate surrounding workspace.
- Page 7 PROTECT THE ENVIRONMENT Take left over materials to an authorised collection point or follow the stipulations in the country where the machine is used. Do not discharge into drains, soil or water. STORE IDLE EQUIPMENT When not in use, the machine should be stored in a dry location. Keep the machine away from children and others not qualified to use it.
-
Page 8: Unpacking
UNPACKING At least 2 people are required to unpack the log splitter. Following the diagrams below, carefully unpack the log splitter, using B and C to support package A. CONTENTS Log Splitter - x1, Control Lever and Guard Assembly - x2, Support Table - x1, Owner’s Manual - x1,... -
Page 9: Set Up & Preparation For Operation
SET UP & PREPARATION FOR OPERATION STEP 1 Pull Spring Pin (A) to remove Lock Pin (B). Apply a thin coat of grease to both surfaces of the Control Lever Guard as shown. Insert Control Lever & Guard Assembly, ensure the Control Lever End fixes into the slot of the Connection Bracket (C). - Page 10 MOVING MACHINE TO WORK AREA The log splitter is equipped with 2 wheels for minor movement. Prior to any movement, ensure the Oil Tank Cover/Breed Screw is secure. To move the machine, stand at the rear, grab handle A and tilt the machine towards you slightly, being careful not to over balance.
-
Page 11: Operation
OPERATION DANGER Keep clear of moving parts! To be operated by one person only! AIR BLEEDER IMPORTANT Before operating the log splitter, the Air Bleeder should be loosened a few rotations until air can go in and out of the oil tank smoothly. Air flow through the Air Bleeder should be noticeable when the log splitter is working. - Page 12 SPLITTING LOGS Plan your work site. Work safely and save effort by planning your work beforehand. Have your logs positioned where they can be easily reached. Prepare an area to stack the split wood or load it onto a nearby truck or other carrier. •...
- Page 13 Before initial operation, check that the two-handed operation is properly functioning by following these steps: a) Lower both control levers, the wedge should lower to approx. 5cm above the table at the highest position. b) Release either of the levers, the wedge should remain in its original position. c) Release both levers, the ram should rise to the highest position automatically.
-
Page 14: Maintenance & Storage
MAINTENANCE & STORAGE REPLACING THE HYDRAULIC OIL The hydraulic system is a closed system with an oil tank, oil pump and control valve. Check the oil level regularly with the dipstick. Low oil levels can damage the oil pump, check the dipstick which is built into the air breather, the oil level should be between the two marks, approx. - Page 15 SHARPENING WEDGE This log splitter is equipped with a reinforced splitting wedge. The blade is specially treated. After long periods of operation, and when required; sharpen the wedge using a fine-toothed file removing any burrs or flat spots on the edge. WIRING DIAGRAM PLUMBING DIAGRAM STORAGE...
-
Page 16: Trouble Shooting
TROUBLE SHOOTING PROBLEM PROBABLE CAUSE REMEDY SUGGESTED No current in the socket Check mains fuse Motor does not start Electrical extension line defective Unplug, check and replace Switch or capacitor defective Have checked by Electrician Valve is not opened due to the Check and tighten the parts connection parts loosening Control levers or connection parts... -
Page 17: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: 3000 Watt Vertical 7 Ton Electrical Log Splitter Model(s): THPLS7TE-A Product Number: 1938139001 Type/Serial No: As per rating label on machine Complies with the following directives: 2006/42/EC-Annex 1 –... -
Page 18: Parts Lists & Diagram
PARTS DIAGRAM... - Page 19 PARTS LIST...
- Page 20 GJ HANDY & CO LTD USER WARRANTY POLICY Users Statement of Warranty Each new machine is warranted against defective material or assembly of material under normal usage. The warranty applies to the original purchaser and covers faulty parts and the labour involved in replacing and repairing those parts, which are of original manufacture.
- Page 21 GJ HANDY & CO LTD USER WARRANTY POLICY Not covered by this warranty a) The warranty policy does not cover any depreciation or damages caused by ordinary wear, rusting or corrosion, lack of correct maintenance or operation, misuse, abuse, lack of transportation or accident.
- Page 22 NOTES _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________...
-
Page 24: Email: Customerservice@Handydistribution.co.uk
For spares or support of your Handy product, please contact us: Tel: 01793 333212 (Mon – Fri 8.00am to 5.30pm excl. Bank Holidays) Email: customerservice@handydistribution.co.uk To see our range of garden machinery & equipment visit: www.thehandy.co.uk Making gardening easier & affordable since 1938 Distributed by Handy Distribution, Murdock Road, Dorcan, Swindon, SN3 5HY...
