UIROBOT SCARA Robot
2.3
Part Names and Outer Dimensions
UI-SR 4150LS
Upper Outer Cover
Lower Outer Cover
Network Port X2
While the LED lamp is on, the current is being applied to the robot. Performing any
work with the power ON is extremely hazardous and it may result in electric shock
and/or inproper function of the robot system. Make sure to turn OFF the controller
power before the maintenance work.
Page 14
LED Lamp
Master Arm
Deputy Arm
Lead Screw
Label Box
LED Lamp
M4220161122CN
Base
Fan Hole
Multifunction
I/O Port X4
Output Port X3
Power Port X1
UI Robot Technology Co. Ltd.
