Service Manual
Installation

Oil flow direction

Tightening Torques

Max. tightening torques – Connection Threads Type G (ISO 228/1)
Ports
Sealing thread
With steel washer
With cooper washer
With aluminium washer
With cutting edge
14
PVG 120 Proportional Valve Group
Mechanical / electrical actuation
A
P B
B
A
P B
B
Max. tightening torques
PA, PB
G 1/4
35 N•m [310 lbf·in]
30 N•m [270 lbf·in]
30 N•m [270 lbf.in]
35 N•m [310 lbf.in]
520L0247 • Rev JA • May 2014
Mechanical / hydraulic actuation
V310169.A
V310162.A
MA
G 1/4
40 N•m [350 lbf·in]
20 N•m [180 lbf·in]
30 N•m [270 lbf.in]
40 N•m [350 lbf.in]
A
P A
B
P B
P A
P
V310163.A
A
P A
B
P B
P A
P
V310170.A
LS, LX, PP
G 3/8
60 N•m [530 lbf·in]
35 N•m [310 lbf·in]
40 N•m [350 lbf·in]
60 N•m [530 lbf·in]
