Service Manual

PVG 120 sectional view

6
PVG 120 Proportional Valve Group
PVG 120 sectional view
X-X
11
10
12
11
P A
13
3
LS
P B
13
3
Legend:
1 – Main spool
2 – Pressure adjustment spool in PVP
3 – Shuttle valve
4 – Pressure relief valve in PVP
5 – Pressure compensator in PVB
6 – LS pressure relief valve in PVB
520L0247 • Rev JA • May 2014
4
T T
P
X
X
2 A 1 B
9
T T
P
A B
7 5 1 8
T T
P
5
6
7 – Shock and suction valve PVLP
8 – Suction valve PVLA
9 – Orifice, closed center PVP; Plug, open center PVP
10 – LS connection
11 – Orifice, open center PVP
12 – Plug, closed center PVP
p
ma
V310100.A
