Getting Started - Quick Install & Test
This guide provides important safety information which should be
read thoroughly before permanently installing the adapter.
1. Connect the 8301 Paging Adapter & Scheduler to an IEEE 802.3af
compliant PoE network switch. The blue lights on the front will
remain on until boot up is completed – about 30 seconds.
2. After the blue lights turn off,
IP address over the analog outputs (eg. headset can be connected to
the green output port).
downloading the Algo locator tool to find Algo devices on your
network:
3. Connect the adapter LINE OUT to an amplifier using the mini-XLR
connector or pluggable terminal block.
4. Access the 8301 Paging Adapter & Scheduler web page by entering
the IP address into a browser (Chrome, IE, Firefox etc) and login
using the default password algo.
5. Enter the IP address for the SIP server into the SIP Domain field
under the BASIC SETTINGS > SIP tab.
6. Enter the page SIP extension and password. (Note the adapter
supports two types of SIP extensions. The page extension auto-
answers for voice page announcements. The ring extension plays an
audio WAV file over the speaker without answering.)
7. Make a call to the adapter by dialling the page SIP extension of the
adapter from a telephone.
Document 90-00070
2017-08-30
Page 12
The IP address may also be discovered by
www.algosolutions.com/locator
Algo Communication Products Ltd
4500 Beedie St Burnaby BC Canada V5J 5L2
www.algosolutions.com
8301 Paging Adapter & Scheduler (FW 1.5)
press the reset switch (RST) to hear the
