- Page 1 1021 USB Dual Handset Adapter for Nortel 1100-Series IP Phones User Guide Document#: 90-00039 sales@algosolutions.com support@algosolutions.com www.algosolutions.com...
-
Page 2: Table Of Contents
Algo 1021 USB Dual Handset Adapter User Guide Table of Contents About the USB Dual Handset Adapter ...... 3 Keypad Functions............3 Volume Control ............3 Audio States ............. 4 Normal ..............4 Mute..............4 Exclude..............4 Installation and Setup ..........5 Setup Diagram ............ -
Page 3: About The Usb Dual Handset Adapter
About the USB Dual Handset Adapter: Keypad Functions About the USB Dual Handset Adapter The 1021 USB Dual Handset Adapter allows two people to share a Nortel IP Phone 1100 Series so they can join in on the same telephone call. Capable of supporting any... -
Page 4: Audio States
About the USB Dual Handset Adapter: Audio States Soft clicks are provided when pressing volume keys until maximum or minimum level is reached. The audio level settings will reset to default after 60 seconds of silence to the receiver. Audio States There are three audio states per user: 1. -
Page 5: Installation And Setup
Installation and Setup: Setup Diagram Installation and Setup Setup Diagram USB Dual Handset 1100 Series IP Phone Adapter Fasten connecting arm of USB Dual Handset Adapter to IP Phone with supplied screws Wheel Tilt Lever USB Connection USB Dual Handset IP Phone Ports Adapter Ports PC Port... -
Page 6: Connect Usb Cable
Installation and Setup: Installation Instructions Wheel on the Adapter to release the adjustment mechanism. To open stand, push Tab down to release latch while lifting up at other end 3. At the back of the IP phone, remove the rubber plug from the Accessory Expansion Module (AEM) port and plug it into a sim- ilar port on the USB Dual Handset Adapter. -
Page 7: Adjust The Stand Angles
Installation and Setup: Configure the IP Phone 6. Adjust the combined IP Phone and USB Adjust the Stand Angles Dual Handset Adapter stands to the desired angle. Then turn the wheel on the adapter to tighten its stand in place. Configure the IP Phone The USB Dual Handset Adapter is a USB device and the IP Phone must be set to... -
Page 8: Standard Two-Handset Configuration
Installation and Setup: Standard Two-Handset Configuration 3. Select Headsets. 4. Under Active Headset Device, select USB then press the Apply key to save the changes to the phone. 5. Proceed with Standard or Optional Head- set configuration as described further on in this User Guide. - Page 9 Installation and Setup: Standard Two-Handset Configuration In this configuration, both handsets are connected to the USB Dual Handset Adapter. To do this: 1. Disconnect the coiled handset cable from the IP Phone handset port and connect it to the bottom left connector of the USB Dual Handset Adapter.
-
Page 10: Two Handsets With Headset Configuration
Installation and Setup: Two Handsets with Headset Configuration Two Handsets with Headset Configuration Headset In this configuration, the primary user can use ONLY the handset of the IP Phone; OR a headset AND handset connected to the USB Dual Handset Adapter. 1. -
Page 11: Regulatory Information
TV technician for help. The user should not make changes or modifications not expressly approved by Algo Communication Products Ltd. Any such changes could void the user's authority to operate the equipment. - Page 12 Algo Communication Products Ltd. 4500 Beedie Street Burnaby, BC Canada V5J 5L2 www.algosolutions.com Sales & Support: Toll-free (USA or Canada): 1-877-884-2546 Or 1-604-454-3790 sales@algosolutions.com support@algosolutions.com...
