Pro-face PS-3710A Series Hardware Manual

Hide thumbs Also See for PS-3710A Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Industrial automation
Elincom Group
European Union: www.elinco.eu
Russia: www.elinc.ru

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS-3710A Series and is the answer not in the manual?

Questions and answers

Related Manuals for Pro-face PS-3710A Series

Summary of Contents for Pro-face PS-3710A Series

  • Page 1 Industrial automation Elincom Group European Union: www.elinco.eu Russia: www.elinc.ru...

  • Page 2: Preface

    Preface Thank you for purchasing Pro-face’s PS-3710A/PS-3711A Series (Hereafter referred to as the “PS-A unit”). Before operating your PS-A unit, be sure to read this manual to familiarize yourself with the PS-A unit’s operation procedures and features. NOTICE Copying this manual’s contents, either in whole or in part, is prohibited without the express permission of Digital Electronics Corporation, Japan.

  • Page 3: Essential Safety Precautions

    Essential Safety Precautions All safety-related procedures stated in this document must be followed to operate the PS-A correctly and safely. Be sure to read this and any related documents thoroughly to understand the correct operation and functions of the PS-A unit. Safety Icons Throughout this manual, these icons provide essential safety information for PS-A operation procedures requiring special attention.
  • Page 4 The PS-A uses a lithium battery for backing up its internal clock data and the battery may explode if it is replaced incorrectly. When replacement is required, use a Pro-face-designated replacement product. SEE “4.6 Replacing the Internal Battery” (page 4-13)
  • Page 5 Installation Be sure all cable connectors are securely attached to the PS-A unit. A loose connection may cause incorrect input or output signals. Wiring Be sure to ground the PS-A unit’s FG wire separately from other equipment FG lines. Also, be sure to use a grounding resistance of 100Ω...
  • Page 6 Do not operate or store the PS-A in locations where it can be exposed to direct sunlight, high temperatures, excessive dust, moisture or vibration. Do not operate or store the PS-A where chemicals evaporate, or where chemicals are present in the air. Corrosive chemicals: Acids, alkalines, liquids containing salt Flammable chemicals: Organic Solvents Do not use paint thinner or organic solvents to remove dirt or oil from the PS-A unit’s surface.

  • Page 7: Information Symbols

    • Installation Guides for various optional items • PS-3710A/PS-3711A specifications may change when optional items are used. Check the optional item installation guides’ specifications for variances, if any. The manuals can be downloaded from Pro-face Home Page, “Otasuke Pro!”. “Otasuke Pro!” URL http://www.pro-face.com/otasuke/...

  • Page 8: Ps-3710A/Ps-3711A Series Model Names

    PS-3710A/PS-3711A Series Model Names The term “PS-3710A/PS-3711A” Series refers to the following numbers: Series Models Type PS3710A-T41 PS-3710A Series AC Power Supply Type PS3710A-T42 PS-3710A Series PS3710A-T41-24V PS-3710A Series DC Power Supply Type PS3710A-T42-24V PS3711A-T41 PS-3711A Series AC Power Supply Type...

  • Page 9: Package Contents

    Information (1) USB Cable Clamp: (2 ports) 2 Power Connector: 1 DC Power Supply type AC Power Supply type (only for PS-3710A Series (only for PS-3711A Series (for AC Power Supply type) DC Power Supply type) DC Power Supply type) (5.08mm [0.2in.] pitch)

  • Page 10: Ul/C-Ul/Csa Approval

    UL/c-UL/CSA Approval • UL listed products see [a] in the Industrial Control Equipment refer to UL508 “Product List“ Suitable for use in Class I, Division 2, Groups A, B, C, and D Hazardous (clas- refer to see [b] in the sified) locations, or Non-Hazardous ANSI/ISA 12.12.01 “Product List“...
  • Page 11 <Cautions> Be aware of the following items when building the PS-A into an end-use product: • The PS-A unit’s rear face is not approved as an enclosure. When building the PS-A unit into an end-use product, be sure to use an enclosure that satisfies standards as the end-use product’s overall enclosure. •...
  • Page 12 <Control Drawing of USB I/F on PS-A's Front Module> The information below concerns the use of the USB I/F located on the PS-A unit's front modules used in Class I, Division 2 Groups A, B, C, and D hazardous locations (from Doc No. 35016429). PS-A’s Front module USB Pin Description 1.

  • Page 13: Ce Marking

    CE Marking PS3710A-T41/PS3710A-T42/PS3711A-T41/PS3711A-T42 units are CE marked products that conform to EMC directives and Low Voltage Directives EN55011 Class A, EN61000-6-2, and EN60950-1. PS3710A-T41-24V/PS3710A-T42-24V/PS3711A-T41-24V/PS3711A-T42-24V units are CE marked products that conform to EMC directives EN55011 Class A and EN61000-6-2. FCC Statement The following units conform to the FCC Rules.

  • Page 14: Table Of Contents

    1.3.2 PS-3711A Series....................1-9 1.4 Prior to Operating the PS-A Unit..............1-12 1.4.1 Power Supply......................1-12 Chapter 2 Specifications 2.1 PS-3710A Series .................... 2-2 2.1.1 General Specifications ..................2-2 2.1.2 Performance Specifications ..................2-6 2.1.3 Interface Specifications ..................2-8 2.1.4 Dimensions ......................2-18 2.2 PS-3711A Series................... 2-21 2.2.1 General Specifications ..................2-21...
  • Page 15 4.1 Cleaning the Display..................4-2 4.2 Cleaning the Fan Filter ................... 4-2 4.3 Periodic Check Points..................4-3 4.4 Replacing the Installation Gasket ..............4-4 4.5 Replacing the Backlight .................. 4-6 4.5.1 PS-3710A Series ....................4-7 4.5.2 PS-3711A Series....................4-10 4.6 Replacing the Internal Battery ..............4-13...

  • Page 16: Chapter 1 Overview

    Overview 1. System Design 2. Accessories 3. Part Names and Functions 4. Prior to Operating the PS-A Unit This chapter describes peripheral devices that can be connected to PS-A Series units along with the name and functions of each part.

  • Page 17: Ps-3710A Series

    PS-3710A/PS-3711A Series Hardware Manual 1.1 System Design 1.1.1 PS-3710A Series The following diagram illustrates the standard range of items that can be connected to PS-3710A Series units. PS-3710A Series *1*2 IDE I/F *1*2 Main Memory Module Main Memory I/F Peripherals...

  • Page 18: Ps-3711A Series

    Chapter 1 Overview 1.1.2 PS-3711A Series The following diagram illustrates the standard range of items that can be connected to PS-3711A Series units. PS-3711A Series *1*2 IDE I/F *1 *2 Main Memory Module Main Memory I/F Peripherals COM1/COM2 (commercial type) RS-232C Cable Peripherals COM2...

  • Page 19: Accessories

    PS-3710A/PS-3711A Series Hardware Manual 1.2 Accessories All accessories listed here are produced by Digital Electronics Corporation. 1.2.1 Option Items Product Name Model No. Description PSA-DDR512 Memory module 512MB DIM module PSA-DDR1G Memory module 1GB HDD Unit mounted a Type 2.5 Parallel ATA Hard Disk (40GB minimum without OS) PS365XA-HD40...

  • Page 20: Maintenance Items

    The appropriate replacement backlight depends on your PS-A model. When LED backlight is used for your PS-A, it is not user-replaceable. For the backlight type you use, refer to the following information. • PS-3710A Series " Display Functions" (page2-7) • PS-3711A Series " Display Functions" (page2-26) When the LED backlight needs to be replaced, please contact your local PS-A distrib- utor.

  • Page 21: Part Names And Functions

    PS-3710A/PS-3711A Series Hardware Manual 1.3 Part Names and Functions 1.3.1 PS-3710A Series A: Power LED / RAS Status Lamp (POWER) PS-A Status Green (lit) Normal Operation (power is on) Green Soft OFF state (blinking) System Monitor Error Orange (lit) Touch Panel Self Test Error...
  • Page 22 Chapter 1 Overview PS-3710A Series DC Power Supply Type N: USB Interface (USB) 4 ports. USB 2.0 compatible. Uses a “TYPE-A” connector. Power supply voltage 5V DC ±5% Each port: 500mA(max.), Output current 5 ports total: Bottom 500mA(max.) Maximum PS-3710A Series DC Power Supply Type...
  • Page 23 PS-3710A/PS-3711A Series Hardware Manual X: Mic Input Interface (MIC IN) 1 port. (standard type AUDIO jack) Y: RAS Interface (RAS) D-Sub 25-pin plug type. Z: Cooling FAN 1: CF Card Interface Cover CF Card interface is under the cover. Type II-compliant slot.

  • Page 24: Ps-3711A Series

    Chapter 1 Overview 1.3.2 PS-3711A Series A: Power LED/RAS Status Lamp (POWER) PS-A Status Normal Operation (power Green (lit) is on) Green Soft OFF state (blinking) System Monitor Error Orange (lit) Touch Panel Self Test Error Orange/Red Backlight burnout is Front (blinking) detected...
  • Page 25 PS-3710A/PS-3711A Series Hardware Manual G: PCMCIA Interface (PCMCIA) 2 ports. PCMCIA Type II, Type III can be available. Corresponding to CARD BUS (Excluding VIDEO ZOOM, SOUND functions) H: Ethernet Interface (LAN1) 10BASE-T/100BASE-TX Auto Changeover. This interface uses an RJ-45 type modular jack connector (8 pins).
  • Page 26 Chapter 1 Overview • When attaching peripheral units to the PS-A, be sure the PS-A's power cord is disconnected from the main power supply. 1-11...

  • Page 27: Prior To Operating The Ps-A Unit

    PS-3710A/PS-3711A Series Hardware Manual 1.4 Prior to Operating the PS-A Unit 1.4.1 Power Supply About states of PS-A’s power supply, there are three kinds of states, which are No Energization, Active State (Normal), and Soft OFF State . Each state is outlined in the following. Power State: No Energization Active State (Normal) Soft OFF...

  • Page 28: Chapter 2 Specifications

    Specifications 1. PS-3710A Series 2. PS-3711A Series This chapter describes the general, functional and interface specifications of the PS-A as well as its part names and dimensions.

  • Page 29: General Specifications

    PS-3710A/PS-3711A Series Hardware Manual 2.1 PS-3710A Series 2.1.1 General Specifications Electrical Specifications PS-3711A Series DC Power PS-3710A Series AC Power Supply Type Supply Type (PS3710A-T41-24V (PS3710A-T41/PS3710A-T42) /PS3710A-T42-24V) Input Voltage AC100/240V DC24V Rated Voltage AC85 to 265V DC19.2 to 28.8V Rated Frequency...
  • Page 30 Chapter 2 Specifications Environmental Specifications Surrounding Air 0 to 50°C: without HDD Temperature 5 to 50°C: with HDD Storage −20 to +60°C Temperature Ambient Humidity 10 to 90%RH (Not condensing, wet bulb temperature: 29°C or less.) Storage Humidity 10 to 90%RH (Not condensing, wet bulb temperature: 29°C or less.) Dust Free of dust Pollution Degree...
  • Page 31 35°C no higher than 64% RH at 40°C no higher than 44% RH • In order to extend the lifetime of the hard disk, Pro-face recommends you set the ® Windows 2000's [Control panel]-[Power Options]-[Turn off hard disks] selection ®...
  • Page 32 Chapter 2 Specifications Structural Specifications Grounding resistance of 100Ω 2mm or thicker wire, Grounding or your country’s applicable standard. (Same for FG and SG terminals) Rating: Equivalent to IP65f NEMA #250 TYPE 4X/12 (When Not Using front-face USB Port unit. When installing Structure Panels.) Feature size: All-in-one...

  • Page 33: Performance Specifications

    PS-3710A/PS-3711A Series Hardware Manual 2.1.2 Performance Specifications Performance Specifications ® ® Intel Pentium M 1.6GHz (Banias) L2 Cache Memory 1MB (Built in the CPU) Main Memory 2Slots (Max.2GB) SO-DIMM socket 256MB to 1GB (PC2700) ® ® Chipset Intel 855GME GMCH and Intel ICH-4 ®...
  • Page 34 Chapter 2 Specifications If “Serial” is selected, COM4 cannot be used. To change the Master/Slave setting of Primary IDE I/F, set Serial Mode Select switch #5 pin on the circuit board to the desired position. Switches (page 2-11) Available only for reading CD/DVD-ROM and DVD-VIDEO. The clock, RTC, built-in the PS-A has a timing error.

  • Page 35: Interface Specifications

    PS-3710A/PS-3711A Series Hardware Manual 2.1.3 Interface Specifications This section describes the specifications of each interface of the PS-3710A Series unit. Serial Interface (COM1,COM2,COM3,COM4) The PS-A unit side connector is a D-Sub 9 pin plug type. Interfit Bracket #4-40 (UNC) • Do not connect any pins to COM3 [NC].
  • Page 36 Chapter 2 Specifications COM3 COM3 can be changed to either RS-232C, RS-422 or RS-485. (The factory setting is RS-232C.) To change this setting, open the PS-A unit's rear cover and set slide switch on the circuit board to the desired position. Switches (page 2-11) •...
  • Page 37 PS-3710A/PS-3711A Series Hardware Manual RS-485 Signal Name Direction Meaning DATA + Input / Output Send/Receive Data (+) DATA - Input / Output Send/Receive Data (-) No Connection No Connection Signal Ground (SG) No Connection No Connection No Connection No Connection Frame Ground (Common with SG) 2-10...
  • Page 38 Chapter 2 Specifications Switches The following switch settings corresponding to each Serial Interface need to be signified. To set the switches which are on the PS-A’s circuit board, remove the PS-A’s Rear Cover. Please refer to "3.2.1 Removal/ Attachment the Rear Cover" (page 3-6). The switches are located as follows; 123456789 10 123456789 RS232C...
  • Page 39 This Soft OFF State is different from what is System ® Standby set by Windows ® When built in Pro-face's Windows XP Embedded, the factory setting is ON. The Setting up an enabled/Disabled state for USB port execution control function is available for ®...
  • Page 40 Chapter 2 Specifications RS-485 RS-485 (Data is not (Data is automati- automati- Switch Description RS-232C RS-422 cally con- cally con- trolled via the trolled via the RTS sig- RTS sig- nal.) nal.) Used by the system. No Connection No Connection Changes COM3's RS-422 / communication...
  • Page 41 PS-3710A/PS-3711A Series Hardware Manual Serial Mode Select Switches (SW4 to SW10) operate as shown in the circuit diagram below. To enable RTS automatic control of the TX output driver, be sure to set SW No. 9 and 10 ON, and set SW No.4 OFF.
  • Page 42 Chapter 2 Specifications RAS Interface The PS-A unit side connector is a D-Sub 25 pin plug type. Interfit Bracket #4-40 (UNC) Pin Arrangement Pin No. Signal Name Meaning Ground Output Current:100mA or less (with a total of 2 pin and 15 pin) Output Voltage:5V±5% Output Current:100mA or less +12V...
  • Page 43 PS-3710A/PS-3711A Series Hardware Manual General-Purpose Input (DIN 0 to 3, RST) Input Voltage DC12V to 24V Input Method Sink / Source Input Input Current 10mA ( DC24V ) Input Resistance 3.6kΩ 5 points ( common with external Input Points reset input ) ON voltage DC10V or more Operation...
  • Page 44 Chapter 2 Specifications General-Purpose Output (DOUT 0 to 3) Rated Voltage DC12V to 24V Maximum Load Current 120mA/point 1.5V or less Out Voltage Drop (at 100mA load current) Output Points 4 points Isolation Method Photocoupler Isolation Dielectric Strength 500V or more Voltage External Power Supply DC12V / 200mA, DC5V / 100mA...

  • Page 45: Dimensions

    PS-3710A/PS-3711A Series Hardware Manual 2.1.4 Dimensions The following dimensions apply to PS-3710A Series. (This figure shows an AC Power Supply type. DC Power Supply type has same dimensions.) Installation Fasteners Attached Dimensions Unit: mm[in.] 382 [15.04] 160 [6.30] 160 [6.30] +0.2...
  • Page 46 Chapter 2 Specifications Cable Attached Dimensions Unit: mm[in.] 383 [15.08] 54.5 [2.15] Left Side Rear Right Side Bottom • All the above values are designed in case of cable bending. The dimensions given here are representative values depending on the type of connection cable used.
  • Page 47 PS-3710A/PS-3711A Series Hardware Manual Panel Cut Dimensions Unit: mm[in.] +0.04 383.5 [15.10 −0 −0 4-R3[0.12] or less Panel thickness area 1.6[0.06] to 10.0[0.39] • Please read "3.1.1 Installation (page 3-2)" before designing the Panel Cut. Installation Fasteners Unit: mm[in.] 16[0.63] 16.6[0.65] 31[1.22] 2-20...

  • Page 48: Ps-3711A Series

    Chapter 2 Specifications 2.2 PS-3711A Series 2.2.1 General Specifications Electrical Specifications PS-3711A Series DC Power PS-3711A Series AC Power Supply Type Supply Type (PS3711A-T41-24V (PS3711A-T41/PS3711A-T42) /PS3711A-T42-24V) Input Voltage AC100/240V DC24V Rated Voltage AC85 to 265V DC19.2 to 28.8V Rated Frequency 50/60Hz Drop 1 cycle or less (Voltage Allowable Voltage...
  • Page 49 PS-3710A/PS-3711A Series Hardware Manual AC Power Noise Voltage: 1,500Vp-p(via noise simulator) Supply Pulse Duration: 50ns, 500ns, 1µs type Rise Time: 1ns Noise Immunity DC Power Noise Voltage: 1,000Vp-p(via noise simulator) Supply Pulse Duration: 50ns, 500ns, 1µs type Rise Time: 1ns Electrostatic Discharge 6kV (complies with EN 61000-4-2 Level 3) Immunity...
  • Page 50 35°C no higher than 64% RH at 40°C no higher than 44% RH • In order to extend the lifetime of the hard disk, Pro-face recommends you set the ® Windows 2000's [Control panel]-[Power Options]-[Turn off hard disks] selection ®...
  • Page 51 PS-3710A/PS-3711A Series Hardware Manual Structural Specifications Grounding resistance of 100Ω 2mm or thicker wire, Grounding or your country’s applicable standard. (Same for FG and SG terminals) Rating: Equivalent to IP65f NEMA #250 TYPE 4X/12 (When Not Using front-face USB Port unit. When installing Structure Panels.) Feature size: All-in-one...

  • Page 52: Performance Specifications

    Chapter 2 Specifications 2.2.2 Performance Specifications Performance Specifications PS3711-T41/ ® ® ULV Intel Celeron M (600MHz) PS3711-T41-24V PS3711-T42/ ® ® ULV Intel Celeron M (1GMHz) PS3711-T42-24V L2 Cache Memory 512KB (Built in the CPU) Main Memory 1Slot (Max.1GB) SO-DIMM socket 256MB to 1GB (PC2700) ®...
  • Page 53 PS-3710A/PS-3711A Series Hardware Manual The clock, RTC, built-in the PS-A has a slight timing error. The range of the error will be between +300 and -300 sec. / month, depending on the PS-A’s conditions such as lifetime usage or temperature difference. If you use the PS-A in a system that takes this error seriously, adjust the clock in regular intervals.

  • Page 54: Interface Specifications

    Chapter 2 Specifications 2.2.3 Interface Specifications This section describes the specifications of each interface of the PS-3711A Series unit. Serial Interface (COM1,COM2) The PS-A unit side connector is a D-Sub 9 pin plug type. Interfit Bracket #4-40 (UNC) • Do not connect any pins to COM2 [NC]. •...
  • Page 55 PS-3710A/PS-3711A Series Hardware Manual COM2 COM2 can be changed to either RS-232C, RS-422 or RS-485. (The factory setting is RS-232C.) To change this setting, open the PS-A unit's rear cover and set slide switch on the circuit board to the desired position. Switches (page 2-30) •...
  • Page 56 Chapter 2 Specifications RS-485 Signal Name Direction Meaning DATA + Input / Output Send/Receive Data (+) DATA - Input / Output Send/Receive Data (-) No Connection No Connection Signal Ground (SG) No Connection No Connection No Connection No Connection Frame Ground (Common with SG) 2-29...
  • Page 57 PS-3710A/PS-3711A Series Hardware Manual Switches The following switch settings corresponding to each Serial Interface need to be signified. To set the switches which are on the PS-A’s circuit board, remove the PS-A’s Rear Cover. Please refer to 3.2.1 Removal/ Attachment the Rear Cover (page 3-6). The switches are located as follows; 123456789 123456789 Inside of the rear...
  • Page 58 This Soft OFF State is different from what is System ® Standby set by Windows ® When built in Pro-face's Windows XP Embedded, the factory setting is ON. The Setting up an enabled/Disabled state for USB port execution control function is available for ®...
  • Page 59 PS-3710A/PS-3711A Series Hardware Manual RS-485 RS-485 (Data is not (Data is automati- automati- Switch Description RS-232C RS-422 cally con- cally con- trolled via the trolled via the RTS sig- RTS sig- nal.) nal.) Used by the system. No Connection No Connection Changes COM2's RS-422 / communication...
  • Page 60 Chapter 2 Specifications Serial Mode Select Switches (SW4 to SW10) operate as shown in the circuit diagram below. To enable RTS automatic control of the TX output driver, be sure to set SW No. 9 and 10 ON, and set SW No.4 OFF.
  • Page 61 PS-3710A/PS-3711A Series Hardware Manual RAS Interface The PS-A unit side connector is a D-Sub 25 pin plug type. Interfit Bracket #4-40 (UNC) Pin Arrangement Pin No. Signal Name Meaning Ground Output Current:100mA or less (with a total of 2 pin and 15 pin) Output Voltage:5V±5% Output Current:100mA or less +12V...
  • Page 62 Chapter 2 Specifications General-Purpose Input (DIN 0 to 3, RST) Input Voltage DC12V to 24V Input Method Sink / Source Input Input Current 10mA ( DC24V ) Input Resistance 3.6kΩ 5 points ( common with external Input Points reset input ) ON voltage DC10V or more Operation...
  • Page 63 PS-3710A/PS-3711A Series Hardware Manual General-Purpose Output (DOUT 0 to 3) Rated Voltage DC12V to 24V Maximum Load Current 120mA/point 1.5V or less Out Voltage Drop ( at 100mA load current ) Output Points 4 points Isolation Method Photocoupler Isolation Dielectric Strength 500V or more Voltage External Power Supply...

  • Page 64: Dimensions

    Chapter 2 Specifications 2.2.4 Dimensions The following dimensions apply to PS-3711A Series. (This figure shows a DC Power Supply type. AC Power Supply type has same dimensions.) Installation Fasteners Attached Dimensions Unit: mm[in.] 382 [15.04] 160 [6.30] 160 [6.30] +0.2 +0.01 [15.08 -0.4...
  • Page 65 PS-3710A/PS-3711A Series Hardware Manual Cable Attached Dimensions Unit: mm[in.] 54.5 [2.15] 383 [15.08] 31.5 [1.24] Left Side Rear Right Side Bottom • All the above values are designed in case of cable bending. The dimensions given here are representative values depending on the type of connection cable used.
  • Page 66 Chapter 2 Specifications Panel Cut Dimensions Unit: mm[in.] +0.04 383.5 [15.10 −0 −0 4-R3 [0.12] or less Panel thickness area 1.6[0.06] to 10.0[0.39] • Please read "3.1.1 Installation (page 3-2)" before designing the Panel Cut. Installation Fasteners Unit: mm[in.] 16[0.63] 16.6[0.65] 31[1.22] 2-39...
  • Page 67 PS-3710A/PS-3711A Series Hardware Manual 2-40...

  • Page 68: Installation • Uninstallation

    Installation and Wiring 1. Installation • Uninstallation 2. Peripheral Devices Installation 3. Wiring Precautions...

  • Page 69: Installation

    Create the correct sized opening required to install the PS-A, using the installation dimensions given. Determine the panel thickness according to the panel thickness range with due consideration of panel strength. PS-3710A Series Panel Cut Dimensions (page 2-20) PS-3711A Series...
  • Page 70 Chapter 3 Installation and Wiring Installation Requirements • For easier maintenance, operation, and improved ventilation, be sure to install the PS-A at least 50mm [1.97in.] away from adjacent structures and other equipment. Unit: mm [in.] [1.97] [1.97] [1.97] [1.97] [1.97] [1.97] [1.97] •...
  • Page 71 PS-3710A/PS-3711A Series Hardware Manual • When installing the PS-A in a slanted panel, the panel face should not incline more than 30°. 30° or less • When installing the PS-A in a slanted panel, and the panel face inclines more than 30°, the surrounding air temperature must not exceed 40°C.
  • Page 72 Chapter 3 Installation and Wiring Installation Panel Hook (3) Insert each of the fasteners, as shown. Be sure to pull the fastener back until it is flush with the rear of the attachment hole. (4) Use a Phillips screwdriver to tighten each fastener screw and secure the PS-A in place.

  • Page 73: Peripheral Devices Installation

    PS-3710A/PS-3711A Series Hardware Manual 3.2 Peripheral Devices Installation A wide variety of optional units, DIM module, CF Cards, manufactured by Pro-face and commercial Expansion boards (PCI bus compatible board), PCMCIA (PC cards) can be used with the PS-A. When installing the optional units, refer to each unit's “Installation Guide”.
  • Page 74 Chapter 3 Installation and Wiring For PS-3710A Series Unscrew the five (5) attachment screws used to hold the Rear Cover in place, and remove the Rear Cover. The torque of the rear cover required for these screws is 0.5 •...

  • Page 75: Ps-A Internal View

    PS-3710A/PS-3711A Series Hardware Manual 3.2.2 PS-A Internal View PS-3710A Series Main Memory Installation Area (2) FDD Drive PCMCIA Slot (2 ports) DVD-ROM Drive HDD Unit PS-3711A Series Main Memory Installation Area (1) PCMCIA Slot (2 ports) HDD Unit CF Card...

  • Page 76: Attaching The Power Switch Cover

    For the AC type to conform to ANSI/ISA standards, the Power Switch cover needs to be attached to the main unit. • • The necessary torque is 0.5N m to 0.6N PS-3710A Series PS-3711A Series 3.2.4 Main Memory Installation (1) Remove the PS-A unit's rear cover. "3.2.1 Removal/Attachment the Rear Cover" (page 3-6) (2) Angle the main memory module down slightly, and push it in until the connector pins mate with the module's pins.
  • Page 77 PS-3710A/PS-3711A Series Hardware Manual (2) Remove the blank panel’s screw, and detach the blank panel. (3) Insert the expansion board (commercial-type PCI) into the expansion board connector, and secure it in • • place using the filler panel’s screw. The necessary torque is 0.5N m to 0.6N Expansion Board Connector Expansion Board...
  • Page 78 Chapter 3 Installation and Wiring • The maximum size allowed for an expansion board is 235mm x 106.68mm [9.25in.x 4.2in.]. When using an expansion board of this size, be sure to secure it in place using the expansion board support cover. Before the rear cover is closed, remove the expansion board support cover screw and be sure the expansion board support cover is detached.

  • Page 79: Pcmcia Unit Installation

    PS-3710A/PS-3711A Series Hardware Manual 3.2.6 PCMCIA Unit Installation (1) Remove the PCMCIA slot cover’s screws (2). PCMCIA Slot Cover (2) [Inserting a commercial-type PC Card] Insert the commercial-type PC Card into the PCMCIA connector. • The PCMCIA slot has 2 connectors. When the PS-A unit is placed as shown below, insert your PC Card with its face up.
  • Page 80 Chapter 3 Installation and Wiring • When using a PC Card with a cable attached, Pro-face recommends you use a clamp or other type of device to prevent vibration from possibly dislodging the cable. • Be sure to stop the PS-A unit PC Card’s driver prior to removing the PC Card. A failure to stop this driver may result in damage to either the PC Card, the PC ®...

  • Page 81: Hdd/Ssd Unit Installation

    PS-3710A/PS-3711A Series Hardware Manual 3.2.7 HDD/SSD Unit Installation Shock Danger! Be sure to unplug the PS-A unit from its power supply prior to installing the HDD unit. • Since the HDD/SSD unit is a precision instrument that has a low resistance to shocks, be sure it is neither hit by nor pressed strongly against another object when installing it.
  • Page 82 Chapter 3 Installation and Wiring When attaching the HDD/SSD to the PS-3711A (1) Place the PS-A unit face down and unscrew eight (8) PS-A unit’s Rear Cover attachment screws (See diagram). • As for AC Power Supply type, remove the power cover as shown below.

  • Page 83: Cf Card Insertion/Removal

    Multi Unit, the CF Card’s internal data, CF Card and the PS-A unit may be damaged or broken. Be sure to use only CF Cards manufactured by the Pro-face. The CF Card’s internal data may be damaged when using another manufacturer’s CF Card.
  • Page 84 Chapter 3 Installation and Wiring When inserting the CF Card For PS-3710A Series (1) Unscrew the CF Card cover's attachment screw (1), and remove the CF Card cover. CF Card Cover (2) Insert the CF Card firmly into the CF Card slot, and check that the eject button pops out.
  • Page 85 Eject Button Removing the CF Card For PS-3710A Series (3) Press the eject button in fully to remove the CF Card from the CF Card slot. (4) After inserting/removing the CF Card, be sure to replace the CF Card cover and secure it in place using the attachment screw.

  • Page 86: Usb Cable Clamp Attachment/Removal

    Chapter 3 Installation and Wiring USB Cable Clamp Attachment/Removal 3.2.9 This clamp is used to prevent the USB cable connected to the USB Host Interface on the bottom of the PS-A unit from being unplugged due to vibration or other causes. Attachment (1) Place the PS-A unit face-down on a flat surface as shown below.
  • Page 87 PS-3710A/PS-3711A Series Hardware Manual Band Band Clamp Clamp Cable collar Cable collar Bridge Bridge USB Cable USB Cable (For PS-3710A) (For PS-3711A) Removing the USB Cable Clamp (1) To remove the clamp from the USB cables, push down on the clamp strap’s clip to release it while pulling up on the clamp.

  • Page 88: Attach The Ps-A Unit To An Arm

    Chapter 3 Installation and Wiring 3.2.10 Attach the PS-A unit to an Arm To attach the PS-A unit to an Arm or to the wall, insert the attachment screws for a commercial-type arm or wall mount adaptor into the holes in the PS-A’s rear face. (Holes specifications: VESA 75mm) For detailed attachment instructions, please refer to that product's installation guide.

  • Page 89: Wiring Precautions

    PS-3710A/PS-3711A Series Hardware Manual 3.3 Wiring Precautions This section describes the procedures and precautions for wiring power cords. 3.3.1 Connecting the Power Cord To avoid an electric shock, prior to connecting the PS-A unit’s power cord terminals to the power terminal block, confirm that the PS-A unit’s power supply is completely turned OFF, via a breaker, or similar unit.
  • Page 90 AI 2.5-12BU (3200962) Recommended Pin Terminal Crimp Tool CRIMPFOX ZA3 (1201882) • Accompanying AC power supply type connector is CA7-ACCNL-01 from Pro-face or FKC2.5/3-STF-5.08 is manufactured by Phoenix Contact. For details, please contact your local Phoenix Contact distributor. Connecting the Power Cord (1) Confirm that the power is not supplied to the PS-A unit.
  • Page 91 AI 1.5-10BK (3200195) AI 2.5-12BU (3200962) Recommended Pin Terminal Crimp Tool CRIMPFOX ZA3 (1201882) • The power supply connector (plug) is CA7-DCCNL-01 from Pro-face, or GFKC2,5/3- STF-7,62 (made by Phoenix Contact For details, please contact your local Phoenix Contact distributor. 3-24...
  • Page 92 Chapter 3 Installation and Wiring Connecting the Power Cord (1) Confirm that the power is not supplied to the PS-A unit. (2) Push the Opening button with a small and flat screw driver to open the desired pin hole. (3) Insert each pin terminal into its each hole. Release the Opening button to clamp the pin in place. Power supply cord Opening Button (4) After inserting all three pins, insert the Power Plug into the Power Connector at PS-A.
  • Page 93 − FG Grounding Terminal connected to the PS-A Insertion Direction • Accompanying DC type power supply connector is CA5-DCCNL-01 from Pro-face or GMVSTBW2.5-3-STF-7.62 (made by Phoenix Contact For details, please contact your local Phoenix Contact distributor. Wiring When connecting the Power Cord, use the following items when performing wiring. (Items are made by Phoenix Contact.)
  • Page 94 Chapter 3 Installation and Wiring Connecting the Power Cord • Be sure to remove the connector from the PS-A unit prior to starting wiring. Failure to do so may cause an electric shock. • The temperature rating of field installed conductors: 75°C only. (1) Confirm that the power is not supplied to the PS-A unit.

  • Page 95: Connecting The Power Supply

    PS-3710A/PS-3711A Series Hardware Manual 3.3.2 Connecting the Power Supply This section describes the precautions for supplying a power voltage. Twisted-pair cord Constant PS-A • If the supplied voltage exceeds the PS-A unit’s range, Voltage connect a constant voltage transformer. Chapter 2 "Specifications" Twisted-pair cord •...

  • Page 96: Grounding

    Chapter 3 Installation and Wiring 3.3.3 Grounding This section describes the precautions for grounding the PS-A unit. Do not use common grounding, since it can lead to an accident or machine breakdown. (a) Exclusive Grounding (BEST) • When supplying power to the PS-A unit, be sure to separate the input/output and power lines, as shown.
  • Page 97 PS-3710A/PS-3711A Series Hardware Manual 3-30...

  • Page 98: Chapter 4 Maintenance

    Maintenance 1. Cleaning the Display 2. Cleaning the Fan Filter 3. Periodic Check Points 4. Replacing the Installation Gasket 5. Replacing the Backlight 6. Replacing the Internal Battery This chapter explains cautions and inspection criteria that will ensure trouble-free use of the PS-A.
  • Page 99 PS-3710A/PS-3711A Series Hardware Manual 4.1 Cleaning the Display When the surface or frame of the display become dirty, soak a soft cloth in water with a neutral detergent, wring the cloth tightly, and wipe the display. • Do not use paint thinner, organic solvents, or a strong acid compound to clean the unit.
  • Page 100 Chapter 4 Maintenance 4.3 Periodic Check Points To keep your PS-A unit in its best condition, please inspect the following points periodically. PS-A Operation Environment Is the operating temperature within the allowable range? PS-3710A: 0°C to 50°C (without HDD) 5°C to 50°C (with HDD) PS-3711A: 0°C to 50°C (without HDD) 5°C to 45°C (with HDD) Is the operating humidity within the specified range? PS-3710A: 10 to 90%RH (Not condensing, wet bulb temperature: 29°C or less.)
  • Page 101 PS-3710A/PS-3711A Series Hardware Manual 4.4 Replacing the Installation Gasket The installation gasket provides protection against dust and moisture. • A gasket which has been used for a long period of time may have scratches or dirt on it, and could have lost much of its water resistance. Be sure to change the gasket at least once a year, or when scratches or dirt become visible.
  • Page 102 Chapter 4 Maintenance • The gasket must be inserted correctly into the groove for the PS-A’s moisture resistance to be equivalent to IP65f. • Since the gasket is flexible but not elastic, be careful not to stretch it unnecessarily, as doing so could tear the gasket. •...
  • Page 103 PS-3710A/PS-3711A Series Hardware Manual 4.5 Replacing the Backlight • The backlights of the PS-A which is marked on Rev.5 cannot be replaced by the user. When the backlight needs to be replaced, please contact your local PS-A distributor. About the Backlight PS-A units use a CFL, long-life type backlight.

  • Page 104: Ps-3710A Series

    CA7-BLU15-01 PS3711A-T42,PS3711-T42-24V 4.5.1 PS-3710A Series Be sure to wear gloves when exchanging the backlight, and follow the following procedures. (1) Turn OFF the power switch of the PS-A and remove the power cable. (2) Remove the PS-A unit from the equipment (panel etc.) to which the unit has been incorporated, and place the PS-A unit on a flat, level surface facing the display face downwards.
  • Page 105 PS-3710A/PS-3711A Series Hardware Manual (5) Insert a screwdriver into the two holes (points) shown below, and remove the backlight attachment screws (1 per hole). FDD unit Insertion Area Insert a screwdriver (2 holes) DVD-ROM Drive (6) Remove the cable from the cable clamp, and detach the cable from the backlight connector on the inverter board.
  • Page 106 Chapter 4 Maintenance (7) Pull out the cable in the direction shown by the arrow. The backlight unit detaches from the backlight unit insertion point. Backlight Unit Cable Backlight Unit Insertion Point • The entire backlight unit should be changed, not just the backlight. (8) Insert the new backlight unit into the backlight holder.

  • Page 107: Ps-3711A Series

    PS-3710A/PS-3711A Series Hardware Manual 4.5.2 PS-3711A Series Be sure to wear gloves when exchanging the backlight, and follow the following procedures. (1) Confirm that the power is not supplied to the PS-A unit, and remove the power cable. (2) Remove the PS-A unit from the equipment (panel etc.) to which the unit has been incorporated, and place the PS-A unit on a flat, level surface facing the display face downwards.
  • Page 108 Chapter 4 Maintenance (5) Remove the cable from the cable clamp, and detach the cable from the backlight connector on the inverter board. Cable Backlight Connector Cable Clamp (6) Pull out the cable in the direction shown by the arrow. The backlight unit detaches from the backlight unit insertion point.
  • Page 109 PS-3710A/PS-3711A Series Hardware Manual • Be sure the cable is inserted completely into the backlight connector. Failure to do so may cause arcing, which can damage the connector. • Be sure to always change both of the PS-A backlights at the same time. (9) Secure both backlights in place using the backlight screw (opposite of step (4)).

  • Page 110: Replacing The Internal Battery

    BIOS settings again after replacing the battery. There is a danger of explosion if the PS-A unit's battery is incorrectly replaced. This battery should be replaced with equivalent type recommended by Pro-face. Prior to replacing the battery, be sure to turn OFF the PS-A unit's power.
  • Page 111 PS-3710A/PS-3711A Series Hardware Manual Battery Replacement Procedure The battery is on the PC board inside the PS-A unit. Refer to “3.2.1 Removal/Attachment the Rear Cover (page 3-6)” for how to open the PS-A unit. (1) Be sure to confirm that power is not supplied to the PS-A unit and open the unit. Internal Battery PS-3710A Internal View PS-3711A Internal View...
