- Page 1 PS-3600G Series Installation Guide...
-
Page 2: Essential Safety Precautions
• Do not connect or disconnect Host and PS-G unit communication cables while the PS-G is turned • The PS-G uses a lithium battery for backing up its internal clock data and the battery may explode if it is replaced incorrectly. When replacement is required, use a Pro-face-designated replacement or an equivalent product. -
Page 3: Installation
Installation • Be sure all cable connectors are securely attached to the PS-G unit. A loose connection may cause incorrect input or output signals. Wiring • Be sure to ground the PS-G unit’s FG wire separately from other equipment FG lines. Also, be sure to use a grounding resistance of 100Ω... - Page 4 * Change the screen image periodically and try to not display the same image for a long period of time. PS-3600G Series Model Names The term “PS-3600G” Series refers to the following PS-G model numbers: Series...
-
Page 5: Package Contents
PS3600G-T41-24V is a UL/c-UL listed product (UL File No. 220851). Product Model No. UL Registration Model No. PS3600G-T41-24V 3384001-12 This product conforms to the following standards: (A) UL508 Industrial Control Equipment (B) CSA-C22.2 No.14-95 (c-UL recognition) Industrial Control Equipment <Cautions> Be aware of the following items when building the PS-G into an end-use product: •... -
Page 6: About The Manual
PS-G distributor immediately. About the Manual The PS-G unit’s CD-ROM contains the following PDF manual files. • PS-3600G Series User Manual (ps3600ge.pdf) ® ® Reading a PDF file requires installation of the Adobe Corporation’s Adobe Reader Adobe Reader 6.0 Installation... -
Page 7: Part Names
Part Names A: Display B: Touch Panel C: Status LED PS-G Status Normal operation Green (lit) Front (power is ON). (Common to PS3600G-T41 Indicates the RAS and PS3600G-T41-24V) Orange (lit) function. Red (lit) System error. Green When accessing CF card. (blinking) Not lit Power is OFF. - Page 8 J: USB Client Interface (TOOL) K: USB Host Interface (USB) Left Side (Common to PS3600G-T41 and PS3600G-T41-24V) Right Side (Common to PS3600G-T41 and PS3600G-T41-24V) L: RAS Interface (RAS) M: Serial Interface (COM2) N K O P Q N: Serial Interface (COM1) Bottom (PS3600G-T41) O: Ethernet Interface (LAN)
-
Page 9: Specifications
R: Dip Switches S: Backup Battery maxell CR2032 With Backup Battery Cover open (Common to PS3600G-T41 and PS3600G-T41-24V) T: CF Card Interface With Backup Battery Cover open (Common to PS3600G-T41 and PS3600G-T41-24V) Specifications Electrical PS3600G-T41 PS3600G-T41-24V Input Voltage AC100V to 240V DC24V Rated Voltage AC85V to 264V... - Page 10 Environmental Ambient Operating 0°C to 50°C Temperature Storage -10°C to +60°C Temperature 10%RH to 90%RH Ambient Humidity (Wet bulb temperature: 39°C max. - no condensation.) Physical 10%RH to 90%RH Storage Humidity (Wet bulb temperature: 39°C max. - no condensation.) Dust 0.1mg/m max.
-
Page 11: Serial Interfaces
Interfaces Serial Interfaces • The PS-G unit’s serial port is not isolated. When the host (PLC) unit is also not isolated, be sure to connect the #5 SG (Signal Ground) terminal to reduce the risk of damaging the RS-232C circuit. •... - Page 12 RS-232C Pin Arrangement Pin No. Signal Name Direction Meaning Input Not Connected RD(RXD) Input Receive Data SD(TXD) Output Send Data Output Not Connected Signal Ground Input Not Connected RS(RTS) Output Request to Send CS(CTS) Input Send Possible ± 5% Output 0.25A Frame Ground Shell (Common with SG)
- Page 13 CF Card Interface For inserting a CF Card. USB Host Interface Conforms to USB1.1. (TYPE-A conn.) Connect a USB connectable device here. USB Client Interface Conforms to USB1.1. (TYPE-B conn.) Use this interface to connect to a personal computer through ActiveSync. Expansion Unit Interface 1 Used to connect an S-GMU bus-compliant Expansion Unit.
-
Page 14: Installation Requirements
Installing Installation Requirements • For easier maintenance, operation, and improved ventilation, be sure to install the PS-G at least 100 mm [3.94 in.] away from adjacent structures and other equipment. Unit: mm [in.] [3.94] [3.94] [3.94] [3.94] [3.94] [3.94] [3.94] •... - Page 15 Installing the PS-G unit in a Panel The PS-G unit is designed to be installed in a Panel. Refer to the following procedure to mount the PS-G unit. (1) Create a Panel Cut on the Panel surface as shown in the panel cut dimensions illustration.
- Page 16 (3) Insert the hook of the installation fastener into the insertion slot of the PS-G unit and tighten the back of the installation fastener using a screwdriver. For the position of the insertion slot, refer to the dimension illustration. Panel Installation Fastener PS-G •...
-
Page 17: Power Cord Specifications
Wiring for the PS3600G-T41 unit (AC100 to 240V) Connect the power cord to the Power Input Terminal Block on the Rear of the PS-G unit. Power Cord Specifications AC Power Cord Grounding Wire Double-insulated Wire 1.25 to 2.0 mm [0.0024 to 0.0062 Power Cord 1.25 to 2.0 mm [0.0024 to 0.0062... - Page 18 Wiring for the PS3600G-T41-24V unit (DC24V) Connect the power cord to the Power Connector using the Power Plug on the Rear of the PS-G unit. Power Cord Specifications 0.2 to 2.5mm [0.0001 to 0.0097inch Power Cord Diameter (24 to 12 AWG) Simple or Twisted Wire Conductor Type [0.28in.]...
-
Page 19: Power Supply Cautions
Connecting the Power Cord When connecting the DC type power cord, be sure to follow the procedures given below. (1) Confirm that the power cord is unplugged from the power supply. (2) Loosen the three screws in the center of the Power Plug. (3) Strip the membrane of the power cord, twist the wire ends, and connect them to the Power Plug. -
Page 20: Grounding Cautions
Grounding Cautions • Be sure to create an exclusive ground for the power cord’s FG terminal. Check that the grounding resistance is less than 100 Ω. • Inside the PS-G unit, the SG (Signal Ground) and FG (Frame Ground) terminals are connected. When connecting an external device to the PS-G using the SG terminal, be sure to check that no short-circuit loop is created when you setup the system. -
Page 21: Peripheral Devices Installation
Peripheral Devices Installation USB Cable Clamp Attachment/Removal This clamp is used to prevent the USB cable connected to the USB Host Interface on the bottom of the PS-G unit from being unplugged due to vibration or other causes. Attachment As shown below, insert the USB Cable Clamp’s band through the Bridge. Pass the USB cables through the Cable Clamp’s band and securely tighten the clamp band around the cables. -
Page 22: Usb Holder Attachment/Removal
USB Holder Attachment/Removal When using a USB device, attaching the USB holder to the USB Host Interface located on the side of the PS-G unit prevents the USB cable from becoming disconnected. Attachment (1) Attach the USB holder to the USB Host Interface part of the main unit. Hook the upper pick of the USB holder to the attachment hole of the main unit and then insert the lower pick as shown below to fix the USB holder. -
Page 23: Replacing The Backlight
Replacing the Backup Battery The PS-G unit has an internal battery for backup of internal clock data. For the procedure for replacing the battery, refer to “PS-3600G Series User Manual”. The Lithium Battery CR2032 is made by Hitachi Maxell, Ltd.
