Backlight Replacement Guide
Thank you for purchasing the PS300-BU00 replacement backlight.
Be sure to read the following Backlight Replacement Warnings prior to replacing your
GP/GLC's backlight.
This replacement backlight package contains the following:
GP/GLC Model
If this backlight is not appropriate for your GP/GLC or does not function correctly, please
contact your local authorized GP/GLC representative.
• Be sure the GP/GLC's power cord has been disconnected prior to chang-
ing the backlight. When the GP/GLC's power cord is connected and the
GP/GLC is ON, high voltage runs through the wires in the backlight area -
do not touch them!
• When the GP/GLC's power cord has just been disconnected, the back-
light area is still very hot! Be sure to wear gloves to prevent being burned.
• The backlight is very fragile. Do not touch the glass tube directly or try to
remove its power cord. If the glass tube breaks you may be injured.
• Do not allow water, oil or fingerprints to remain on the tube, since they
can all reduce the backlight's life.
• When replacing the backlight, be sure to use the correct model back-
light. (Model No: PS300-BU00)
Package Contents
- One (1) Replacement Backlight (Model:PS300-BU00)
Items Required When Changing The GP/GLC's Backlight
- Phillips screwdriver (no. 2) for GP/GLC's cover attachment screws.
- One pair of clean (preferably new) cotton gloves.
GP-2300L
GP-2301L
GP-2300S
GP-2301S
GLC2300L
WARNINGS
Backlight Model No.
PS300-BU00
1
Advertisement
Table of Contents
Related Manuals for Pro-face PS300-BU00
Summary of Contents for Pro-face PS300-BU00
- Page 1 Backlight Replacement Guide Thank you for purchasing the PS300-BU00 replacement backlight. Be sure to read the following Backlight Replacement Warnings prior to replacing your GP/GLC’s backlight. This replacement backlight package contains the following: GP/GLC Model Backlight Model No. GP-2300L GP-2301L...
- Page 2 Backlight Replacement Use the following steps to change the backlight. The backlight unit includes both the tube and holder. Do not attempt to sepa- rate the two, since the unit could break and cause an injury. GP-2300L/2301L/2300S/2301S, GLC2300L Series Unit Backlight Replacement 1) Turn OFF the GP/GLC unit's power supply.
- Page 3 4) Detach the backlight unit’s power connector from the display module White by grasping both of the connector’s removal prongs and pulling gently upwards. Do not pull the connector so strongly as to stretch or break either of the connector wires. Removal Prongs 5) The upper portion of the display module has two lock tabs.
- Page 4 Please be aware that Digital Electronics Corporation shall not be held liable by the user for any damages, losses, or third party claims arising from the uses of this product. Digital Electronics Corporation 8-2-52 Nanko Higashi, Suminoe-ku, Osaka 559-0031, Japan URL: http://www.pro-face.com/ © 2001 Digital Electronics Corporation...
