Cerebot 32MX7 Reference Manual
Connector and Jumper Block Pinout Tables
MCU Port Bit to Pmod Connector Pin
MCU Signal
Port Bit
RA00 TMS/RA0
RA01 TCK/RA1
RA02 SCL2/RA2
RA03 SDA2/RA3
RA04 TDI/RA4
RA05 TDO/RA5
RA06 TRCLK/RA6
RA07 TRD3/RA7
RA09 Vref-/CVref-/AERXD2/PMA7/RA9
RA10 Vref+/CVref+/AERXD3/PMA6/RA10
RA14 AETXCLK/SCL1/INT3/RA14
RA15 AETXEN/SDA1/INT4/RA15
RB00 PGED1/AN0/CN2/RB0
RB01 PGEC1/AN1/CN3/RB1
RB02 AN2/C2IN-/CN4/RB2
RB03 AN3/C2IN+/CN5/RB3
RB04 AN4/C1IN-/CN6/RB4
RB05 AN5/C1IN+/VBUSON/CN7/RB5
RB06 PGEC2/AN6/OCFA/RB6
RB07 PGED2/AN7/RB7
RB08 AN8/C1OUT/RB8
RB09 AN9/C2OUT/RB9
RB10 CVrefout/PMA13/AN10/RB10
RB11 AN11/ERXERR/AETXERR/PMA12/RB11
RB12 AN12/ERXD0/AECRS/PMA11/RB12
RB13 AN13/ERXD1/AECOL/PMA10/RB13
RB14 AN14/ERXD2/AETXD3/PMALH/PMA1/RB14
RB15 AN15/.../OCFB/PMALL/PMA0/CN12/RB15
RC01 T2CK/RC1
RC02 T3CK/AC2TX/RC2
RC03 T4CK/AC2RX/RC3
RC04 T5CK/SDI1/RC4
RC12 OSC1/CLKI/RC12
RC13 SOSCI/CN1/RC13
RC14 SOSCO/T1CK/CN0/RC14
RC15 OSC2/CLKO/RC15
RD00 SDO1/OC1/INT0/RD0
RD01 OC2/RD1
RD02 OC3/RD2
RD03 OC4/RD3
RD04 OC5/PMWR/CN13/RD4
RD05 PMRD/CN14/RD5
RD06 ETXEN/PMD14/CN15/RD6
RD07 ETXCLK/PMD15/CN16/RD7
www.digilentinc.com
Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.
Connector Notes
Pin
JF-07
JF-08
N/A I2C Bus #2, not shared with Pmod connector
N/A I2C Bus #2, not shared with Pmod connector
JF-09
JF-10
JE-07
JE-08
JE-09
JE-10
N/A I2C Bus #1, not shared with Pmod connector
N/A I2C Bus #1, not shared with Pmod connector
N/A Used by debug circuit, PGC
N/A Used by debug circuit, PGD
JA-01
JA-02
JA-03
N/A USB VBUSON
JA-04
JA-07
JA-08
JA-09
JA-10
N/A Ethernet PHY
N/A Ethernet PHY
N/A Ethernet PHY
JC-10
JC-07
JC-01
N/A CAN2 Transceiver
N/A CAN2 Transceiver
JD-03
N/A Primary Oscillator Crystal
N/A Secondary Oscillator Crystal
N/A Secondary Oscillator Crystal
N/A Primary Oscillator Crystal
JD-02
JD-07
JD-08
JD-09
JC-09
JC-08
N/A Ethernet PHY
JC-04
