Control 4 - iNels Connection server User Manual

Control 4

Interconnection Control4 system with iNELS electrical installation via Connection server
Requirements for Control4 integration Central unit iNELS3
Setting up is made in Composer licensed program, the first step is to save iNELS drivers:
iNELS3_Master_Driver.c4i
iNELS3_Switch.c4i
iNELS3_Dimmer.c4i
iNELS3_PIR.c4i
iNELS3_RGB.c4i
iNELS3_Therm.c4i
iNELS3_Thermostat.c4i
iNELS3_Blinds.c4i
copy all the files to the location
(Windows)
Connect to the IP address of the control unit C4 (Director), and then put into the project
, and set the IP address of the Connection server.
iNELS3_Master_Driver
Addition iNELS3 Driver to the project
Procedure: Switch to the System design menu and continue Items window, where the tab Search
and scan a string "iNELS" and insert the selected driver to the project.
The first add iNELS3 Master Driver and after that load other iNELS3 drivers
Insertion IP addresses to the Master Driver
Procedure: Go to the Connections menu where select iNELS3 Master Driver and continue
on the top bookmark Network, after that open iNELS 3 Master Driver and enter the IP address.
Control 4
Director unit HC-250, HC-350, HC-800, EA-3, etc.
Composer software (2.7.2, 2.8.1, 2.8.2 and
higher)
Connection Server 3.219 and higher
- Main driver establish the connection between Connection Server to C4
- Switching unit, SA3
- Dimming units DA3, DAC3
- Intrusion monitoring motion PIR sensor via the input IM3
- RGB light control using RFDA-73m / RGB
- Temperature sensor
- Thermostat produced in IDM (heating, cooling, combined)
- Shutters/Blinds driver for JA3 / 20B / DC, SA3
C:\Users\user\Documents\Control4\Drivers and run Composer pro.
