Levelflex FMP53 FOUNDATION Fieldbus
8.4

Block model

8.4.1 Blocks of the device software
The device has the following blocks:
• Resource Block (device block)
• Transducer Blocks
– Setup Transducer Block (TRDSUP)
– Advanced Setup Transducer Block (TRDASUP)
– Display Transducer Block (TRDDISP)
– Diagnostic Transducer Block (TRDDIAG)
– Expert Configuration Transducer Block (TRDEXP)
– Expert Information Transducer Block (TRDEXPIN)
– Service Sensor Transducer Block (TRDSRVSB)
– Service Information Transducer Block (TRDSRVIF)
– Data Transfer Transducer Block (TRDHROM)
• Function Blocks
– 2 Analog Input Blocks (AI)
– 1 Discrete Input Block (DI)
– 1 PID Block (PID)
– 1 Arithmetic Block (AR)
– 1 Signal Characterizer Block (SC)
– 1 Input Selector Block (IS)
– 1 Integrator Block (IT)
– 1 Analog Alarm Block (AAL)
In addition to the pre-instantiated blocks already mentioned, the following blocks can also be
instantiated:
• 5 Analog Input Blocks (AI)
• 2 Discrete Input Blocks (DI)
• 3 PID Blocks (PID)
• 3 Arithemetic Blocks (AR)
• 2 Signal Characterizer Blocks (SC)
• 5 Input Selector Blocks (IS)
• 3 Integrator Blocks (IT)
• 2 Analog Alarm Blocks (AAL)
Up to 20 blocks can be instantiated in the device altogether, including the blocks already
instantiated. For instantiating blocks, see the appropriate Operating Instructions of the
configuration program used.
Endress+Hauser Guideline BA00062S.
The guideline provides an overview of the standard function blocks that are described in
FOUNDATION Fieldbus Specifications FF 890 - 894. It is designed to help operators use
the blocks implemented in the Endress+Hauser field devices.
