Endress+Hauser Levelflex FMP53 Brief Operating Instructions page 15

Levelflex FMP53 FOUNDATION Fieldbus
6.2.3 Turning the transmitter housing
To provide easier access to the connection compartment or display module, the transmitter
housing can be turned:
8 mm
1. Unscrew the securing screw using an open-ended wrench.
2. Rotate the housing in the desired direction.
3. Tighten the securing screw (1,5 Nm for plastics housing; 2,5 Nm for aluminium or
stainless steel housing).
Endress+Hauser
6 Nm (4.42 lbf ft)
3 m (9 ft) / 6 m (19 ft)
r
= 50 mm (2")
min
max. 350°
Mounting
A0015103
8 mm
A0013713
15
