Summary of Contents for Whirlpool EveryDrop EDRD101G1W

  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION 4–7 Get to know your new Water Dispenser Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. INSTALLATION 8–18 Prepare for installation...
  • Page 3: Introduction

    INTRODUCTION WELCOME TO A NEW WAY TO WATER GET TO KNOW YOUR EVERYDROP WATER DISPENSER Refilling bulky pitchers, rethinking shelf space, and being concerned about contaminants are all behind you. Now you’re ready to enjoy a steady stream of clean water at the push of a button. Let’s get started. FILTER ACCESS DOOR FILTER LOCK/UNLOCK...
  • Page 4: Introduction

    INTRODUCTION WATER SUPPLY REQUIREMENTS IMPORTANT A cold water supply with water pressure between 30 and 120 psi • Plumbing must be installed in accordance with the International (207 and 827 kPa) is required to operate the Water Dispenser and ice maker. Plumbing Code and any local codes and ordinances.
  • Page 5: Installation

    INSTALLATION PREPARING FOR INSTALLATION INSTALLATION OVERVIEW Clean refrigerator surface using a mild dish detergent solution. Dry There are two tubes attached to your Water Dispenser. The house line thoroughly to avoid water spots. connects to your house’s cold water supply. If you have an ice maker, the dispenser’s refrigerator line connects to your refrigerator.
  • Page 6 INSTALLATION MOVE AND UNPLUG REFRIGERATOR SHUT OFF WATER DISCONNECT WATER LINE Excessive Weight Hazard Use two or more people to move and install refrigerator. Failure to do so can result in back or other injury. Slide the refrigerator out so If your refrigerator does not Disconnect the water line you can access the water...
  • Page 7 INSTALLATION EMPTY WATER LINE MOUNT DISPENSER MOUNT TUBING BACK OF WATER DISPENSER Mount the two Tubing Holders to the side of the refrigerator and run the tubing through the holder—do this prior to Empty any excess water that Route the dispenser’s tubing making any water connections.
  • Page 8 INSTALLATION CONNECT TO WATER SUPPLY CONNECT TO REFRIGERATOR WATER LINE PARTS CONNECTION POINT A. Sleeve B. Nut C. Copper tubing (to refrigerator) D. Household supply " line (1/2 min.) HOSE A. Compression sleeve B. Compression C. Copper tubing If you don’t have an ice maker, A.
  • Page 9 INSTALLATION PLUG IN REFRIGERATOR TURN WATER ON AND MOVE IT BACK Excessive Weight Hazard Use two or more people to move and install refrigerator. Failure to do so can result in back or other injury. Plug the refrigerator power Turn your house’s water back cord back into the outlet on.
  • Page 10: Use

    INSTALLATION HOW TO USE THE PRODUCT FLUSH FILTER ENJOY The purpose of the EveryDrop Water Dispenser is to deliver filtered tap water when and where you want it. The built-in magnet allows you to attach the dispenser anywhere on the magnetic surface of your refrigerator. The EveryDrop Water Dispenser includes a pull-out Drip Tray that is intended to catch any drips.
  • Page 11 FILTER SUBSCRIPTION SERVICE THE EVERYDROP WATER DISPENSER REQUIRES EVERYDROP FILTER 1 EveryDrop offers a subscription service to receive replacement filters for (Model Number: EDR1RXD1) your EveryDrop Water Dispenser every 3 or 6 months, depending on your household size and water consumption. •...
  • Page 12 CARE—HOW TO CHANGE THE FILTER UNLOCK OPEN FILTER ACCESS DOOR PULL OUT OLD FILTER INSERT NEW FILTER To change the filter, turn Open the Filter Access Door Pull out the old filter. It’s normal Remove the cap from the top the Filter Lock/Unlock Knob on the top of the dispenser.
  • Page 13: Care

    CARE WATER FILTER REMINDER STICKER TROUBLESHOOTING Enclosed is a Filter Reminder Sticker. Write the filter color (purple) or number If your EveryDrop Water Dispenser is not operating properly, check the following. (Filter 1) on the sticker. Write the replacement date, which is six months from •...
  • Page 14: Warranty

    ® 7. Defects or damage caused by the use of non-genuine Whirlpool parts or accessories original EveryDrop Dispenser returned to us. Your replacement unit will be 8.
  • Page 15: Performance Data Sheet

    WARNING: This product contains one or more chemicals known to the State of California to cause birth defects or other reproductive harm. Customer Support 1 . 8 0 0. 4 6 2 . 3 8 1 9 ®/TM ©2017 Whirlpool. All rights reserved. Whirlpool Corporation Benton Harbor, MI 49022 #2 Nanjing, China. Form No. OA170022B...
